Temperature measurement system PAT-1M

angleopticalvision

Overview
Configure a measurement system matched to your application, research workflow and experimental requirements. The PAT-1M is a profile analysis tensiometer designed for reproducible drop, bubble and interfacial measurements with modular extension options.

Dosing configuration

• Integrated Automatic Dosing — included as standard for reproducible drop and bubble generation.
• Optional: Coaxial Capillary System 1M — an additional coaxial capillary configuration for specialized drop, bubble and interfacial measurement tasks.

Measurement environment

• Standard Measurement Cell — included as standard for surface and interfacial measurements.
• Optional: Temperature Measurement Setup — temperature measurement inside the measurement cell for experiments requiring controlled thermal conditions.

Measurement modules (extendable)

• ODBA-1M — high-frequency interfacial rheology: oscillating drop and bubble analysis for advanced dynamic characterization.
• DPA-1M — capillary/differential pressure analysis for systems with low density differences and specialized interfacial configurations.
• DBMM-1M — interface interaction module for direct drop, bubble and interface interaction experiments.
• SOA (Second Optical Axis) — optical extension for additional observation and analysis of specialized configurations.
• CA-1M — optional module for precise contact-angle measurements.

Accessories

• Additional Capillaries — consumables and measurement accessories selected according to the intended configuration.
• Precision Syringes — additional syringes for reproducible liquid handling and dosing workflows.
• PC — desktop or laptop (Windows) configured with the required SINTERFACE software for instrument operation.

Application scope

• Reproducible drop and bubble generation and analysis.
• Dynamic interfacial characterization and high-frequency interfacial rheology.
• Capillary pressure and low density difference systems analysis.
• Contact-angle and wetting measurements (with CA-1M module).

Technical specifications

• Model: PAT-1M
• Brand: SINTERFACE
• Instrument type: Profile Analysis Tensiometer
• Standard features: Integrated Automatic Dosing; Standard Measurement Cell
• Optional dosing: Coaxial Capillary System 1M
• Optional environmental control: Temperature Measurement Setup
• Available modules: ODBA-1M, DPA-1M, DBMM-1M, SOA, CA-1M
• Accessories: Additional Capillaries, Precision Syringes, Windows PC with SINTERFACE software
• Typical measurements: drop/bubble generation, interfacial tension, interfacial rheology, capillary pressure, contact-angle
