Bottom coverstitch sewing machine ABF100 series

single-needlesingle-threadbutton

Remark : Standard : Professional table, All Set of Button Presser Foot ,Small/Big Button Serrarted Plate and Bottom Plate, 12 Sets of Standard Button Carrier. Option : 3-Holed of Button Carrier,Button Spacer,Button Spacer with Laser Light. *The definition of Button Size: Extra small button size is Φ8~10mm, small button size is Φ10~20mm, and large button size is Φ20 ~ 26 mm. Basically, Button clamp of machine head is applied for Φ8~26mm, but that sewing extra/ large button size are depend on its thickness and convexity. Features Button sewing machine with automatic button feeder enhances 300% efficiency of button sewing. Cycle Time: 2.2 Sec./Button; 13,090 Buttons/8 Hr PANEL User friendly interface, all sewing parameters are clearly shown. SENSOR SIGNAL DETECT Checking the sensors detecting by A02 function of operation panel. FLIP MECHANISM Flip mechanism enhance the accuracy of ø16mm up button by auto air-blow. SMART SENSOR OF BUTTON CLAMP Button clamp can detect the button position and avoid sewing without button.
