Temperature control module easYgen series

industrial

easYgen-1400 has all the functions of the easYgen-400 as well as automatic mains failure function (AMF), which is particularly wellsuited for single automation systems that include mains and generator. easYgen-400 is intended to be used for single automation systems, auto start/stop of the unit is performed using a remote signal. With ARM-based 32-bit SCM, highly integrated hardware, high reliability level. Multilingual interface (English, Chinese, Spanish, Russian, Portuguese,Turkish, Polish, and French) making commissioning convenient for factory personnel. Improved LCD with high wear-resistance and scratch resistance due to hard screen acrylic. Silicon panel and pushbuttons for better operation in high-temperature environments. Equipped with CAN bus port for communicating with the J1939 genset. Monitoring frequently-used data on ECU machine,such as water temperature, oil pressure, speed, fuel consumption, ECU machine, and additionally also control start, stop, raising speed, and speed droop via CAN bus port. Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with voltage 120/240 V and frequency 50/60 Hz. easYgen-1400 only: Collects and shows 3-phase voltage, current, power parameter, and frequency of generator and additionally 3-phase mains voltage. Mains Generator Line voltage(UAB, UBC, and UCA) Line voltage (UAB, UBC, and UCA) Phase voltage (UA, UB, and UC) Phase voltage (UA, UB, and UC) easYgen-400 only: Collects and shows 3-phase voltage, current, power parameter and frequency of generator. Generator Line voltage (UAB, UBC, and UCA) Line voltage (UAB, UBC, and UCA) Phase voltage (UA, UB, and UC)
