Resistance welder SOLDADOR COTT 155single-phaseDCfor steel
Add to favorites
Compare this product
Characteristics
- Technique
- resistance
- Power supply
- single-phase
- Output current
- DC
- Material
- for steel
- Other characteristics
- portable, inverter
- Intensity
150 A
Description
Duty cycle at 40ºC: 35%
Intensity at 60%(100%) 40ºC: 90A (65A)
Regulation: 10-150A (20,4 -26V)
Usable electrodes: 1,6 - 4,0 mm
Connection: 230V - 1Ph
Usable range: 180V - 280V
OCV: 75V
Max. absorbed power: 6,2Kva
Imax: 26A
Ieff: 15,3A
Fuse: 16A
Ventilation: FORZADA
Weight: 3,5Kg
Regulation panel: SOLTER
Norms: EN-60974-1, EN-60974-10
Protection Index: IP23C
Dimensions: 230x120x255mm
VIDEO
Catalogs
KIT SOLDADOR COTT 155
2 Pages
