Tubular heating element MHE 27.0

flexiblewirestainless steel

automatic transfer of "U" folding central annealing group central element end machining units Resistance diameter 6.4 - 8.4 mm. Max length of straight resistances (Li. ).1,200 mm. + / - 1 % Minimum length of resistances 300 mm. Resistance materials. Iron - Stainless Steel Diameter of the bending pin, between 18 and 60 mm. of pin cut (L), between: .9 and 17mm. Length of annealing between ( Lr. ):40 and150 mm. Cycle time:5 – 8 sec., depending on the thickness of the resistance on the length of the section to be annealed Installed power: 62 KWA. Electrical power supply 3 x 400 V – 50 Hz. Pneumatic supply 5.5 bar. Overall dimensions (approx.): 3,500 x 2,500, H = 1,500 mm.
