Pneumatic connector module CTD-C3-3/SdataSocketsocket
Add to favorites
Compare this product
Characteristics
- Type
- data, pneumatic
- Format
- Socket
- Connection type
- socket
- Electrical characteristics
- power, 5-pole, small-signal
- Material
- PE
- Product applications
- cans, manual, wall
- Domain
- fast
- Impedance
50 Ohm
- Primary current
23 A, 31 A
- Voltage
250 V, 300 V, 600 V, 1,000 V
- Operating temperature
Max.: 125 °C
(257 °F)Min.: -40 °C
(-40 °F)
Description
CombiTac direqt contacts are designed to ensure easy and fast assembly, and a reliable solid performance up to 10,000 mating cycles.
Various power, signal and pneumatic contacts can be placed into carriers without the use of tools, while the corresponding carriers are coded to ensure correct polarity during manual insertion into frames.
Power modules, IP2X protection on socket side, PE contacts, tool-free insertion in carriers for 2.5 - 4 mm² conductors (AWG 12 - 14). Socket carriers with protective wall
