Current amplifier SR865A

voltagelock-inbenchtop

The SR865A Lock-In Amplifier offers superb performance and outstanding value. With 4 MHz frequency range, time constants from 1 µs to 30 ks, very low noise front-end amplifiers, and a modern, intuitive user interface, the SR865A is the ideal choice for any synchronous detection application. The SR865A Lock-In Amplifier offers superb performance and outstanding value. It's what you've come to expect from a Stanford Research Systems lock-in amplifier. With 4 MHz frequency range, time constants from 1 µs to 30 ks, very low noise front-end amplifiers, and a modern, intuitive user interface, the SR865A is the ideal choice for any synchronous detection application. With over 30 years of lock-in design experience SRS has made every effort to optimize each detail of the SR865A. From a hefty toroidal transformer that eliminates switch-mode noise to iOS connectivity that brings the lock-in to your cell phone to advanced DSP filters that eliminate more noise while speeding up your experiment, the SR865A is truly the ultimate lock-in amplifier. Trend Graph Lock-in performance starts at the front end. The SR865A front end offers both state-of-the art voltage and current input amplifiers. The voltage input is a switchable single-ended/differential JFET-pair amplifier with 2.5 nV/√Hz of noise at 1 kHz and under 10 nV/√Hz of noise at 10 Hz. The voltage input has a 10 MΩ input impedance and can be AC or DC coupled. Input connector shields can be connected to the instrument ground through a user selectable 10 Ω (Ground) or 10 kΩ (Float) resistor.
