Z-axis positioning stage HT 160
manual1-axishigh-accuracy

Z-axis positioning stage - HT 160 - Steinmeyer Holding GmbH - manual / 1-axis / high-accuracy
Z-axis positioning stage - HT 160 - Steinmeyer Holding GmbH - manual / 1-axis / high-accuracy
Add to favorites
Compare this product

Characteristics

Orientation
Z-axis
Type
manual
Number of axes
1-axis
Other characteristics
high-accuracy, compact, aluminum, for microscopes, vacuum-compatible, industrial, non-magnetic, thin
Stroke

Max.: 16 mm
(0.63 in)

Min.: 1 mm
(0.039 in)

Description

• For applications in industry, research and development • For exact positioning and adjusting of optics, precision workpieces or other test objects Technical data • Load-bearing capacity max. 50 N • Travel range 16 mm • Resolution 0,1 µm Benefits • Option to combine several elements for multi-axis positioning systems • Adaptability to different environmental conditions (for example vacuum) • Drive can be selected individually • Available with customized bore holes • Non-magnetic designs available • Optionally, made from sturdy steel or lightweight aluminium • Low height thanks to lifting wedge principle • Small increments at a comparatively high load Application • For applications in industry, research and development • For exact positioning and adjusting of workpieces or other objects in Z-direction
