Vacuum pressure transmitter 0645

membraneanalogthreaded

Pressure transmitters especially for low pressures, including vacuum applications High overpressure protection (up to 3 x) Long life time even under high pressure change rates Housing and wetted parts are made of stainless Steel providing excellent media compatibility Suitable for hydrogen and oxygen applications” The highly-sensitive piezo-resistive sensor in the measuring cell filled with oil guarantees high level of accuracy, repeatability and long-term stability The availability of différent sealing materials enables deployment in a broad température range with a diverse array of media Output signal: - 0.5 - 4.5 V ratiometric Supply voltage Uv+: - 5 VDC ±10 % max. 6.5 VDC Permissible load / apparent ohmic résistance: - > 4.7 kO Mechanical life expectancy: - 10,000,000 pulsations at rise rates to 1,000 bar/s at pnom Permitted pressure change rate: - 100 MO (35 VDC) Response time 10 - 90 %: - < 2 ms Vibration résistance: - 20 g at 4 - 2000 Hz sine wave; DIN EN 60068-2-6 Shock résistance: - half sine wave 500 m/s2; 11 ms; DIN EN 60068-2-27 Protection class - Refer to the electrical connections
