Multifunction drilling rig SWDB90crawlerdown-the-holehydraulic
Add to favorites
Compare this product
Characteristics
- Applications
- multifunction
- Mobility
- crawler
- Drilling unit
- down-the-hole
- Other characteristics
- hydraulic
- Drilling diameter
Max.: 120 mm
(5 in)Min.: 90 mm
(4 in)- Drilling depth
Max.: 24 m
(78'08" )Min.: 0 m
(0'00" )
Description
Main Parameters
Total weight 12.5t
Working state：L x W x H 4.8×3.05×7.3 (m)
Transportation state：L x W x H 7.3×3.05×3.2 (m)
OPERATION PARAMETER
Drill rod length 4m×6
Drill rod diameter 76mm
Hole diameter 90～120 (mm)
Hole depth, max 24m
Drill hammer DHD3.5
Dust collection device Dry type (standard) / Wet (optional)
AIR COMPRESSOR
Model 425HH
Working pressure 1.05～1.4 (MPa)
Free air delivery 12m3/min
Power 108kW / 2250rpm
ENGINE
Model 4BT3.9
Power / Speed 60kW / 2200rpm
Fuel tank capacity 360L
