Brushless motor FM1 series
BLDC70 V24 V

Brushless motor - FM1 series - Suzhou Honpine Precision Industry Co., Ltd. - BLDC / 70 V / 24 V
Brushless motor - FM1 series - Suzhou Honpine Precision Industry Co., Ltd. - BLDC / 70 V / 24 V
Add to favorites
Compare this product
Go to the Suzhou Honpine Precision Industry Co., Ltd. website for more information

Characteristics

Type
brushless, BLDC
Voltage
24 V, 48 V, 70 V
Configuration
frameless
Applications
for industrial applications, for medical equipment, for robotics, for collaborative robots, for humanoid robot, for medical applications, for rotary tables, for electric actuators, for AMR, with built-in encoder
Other characteristics
high-efficiency, high-torque, low-inertia
Power

Max.: 0.92 kW
(1.25 hp)

Min.: 0.17 kW
(0.23 hp)

Intensity

Max.: 32.2 A

Min.: 6.56 A

Torque

Max.: 9.51 Nm
(7.014216 ft.lb)

Min.: 0.3 Nm
(0.221269 ft.lb)

Rotational speed

Max.: 6,500 rpm
(40,840.7045 rad.min-1)

Min.: 620 rpm
(3,895.5749 rad.min-1)

Diameter

Max.: 115 mm
(4.53 in)

Min.: 50 mm
(1.97 in)

Description

Introduction
HONPINE FM1 frameless Brushless DC (BLDC) motors are compact, high-performance industrial actuators provided in multiple size variants. Available sizes cover approximately φ50 mm to φ115 mm. Rated voltages range from 24 V to 70 V; optional Hall sensors, temperature sensors and wiring configurations are available. Typical uses include collaborative robots, humanoid robots, quadrupeds and medical rehabilitation equipment.

Features
  • High torque density: torque increases by approximately 10% at the same input current.
  • Extended endurance: optimized magnetic circuits and material selection reduce motor losses and extend operating time.
  • Compact frameless structure: removal of housing and redundant components reduces volume by ~40–50% versus standard housed motors, simplifying embedding in tight layouts.
  • Low inertia: lightweight design and application of composite materials enable fast dynamic response for frequent start/stop cycles.
  • Low temperature rise: magnetic circuit optimization reduces losses by ~20%, improving conversion efficiency.
  • Integration-friendly: frameless form factor supports flexible installation and direct mechanical integration into custom gearheads or joints.

Applications
  • Collaborative robots (cobots)
  • Humanoid robot joints
  • Quadruped robots
  • Medical rehabilitation robots and actuators
