USB RFID reader UPC-M05
MIFARENFC

USB RFID reader
USB RFID reader
Add to favorites
Compare this product


Characteristics

Connector type
USB
Other characteristics
MIFARE, NFC
Frequency

13.56 MHz

Description

NFC/RFID Reader Module supports ISO 14443A/B, All bit rates: 106 kbps ISO 15693, all modes Downlink 1 of 3 and 1 of 256 Uplink 6.6/13/26/53 kpbs with 1 & 2 sub-carrier Support Protocols ISO 14443A/B, All bit rates: 106 kbps ISO 15693, all modes Downlink 1 of 3 and 1 of 256 Uplink 6.6/13/26/53 kpbs with 1 & 2 sub-carrier Card Type ISO 14443A MIFARE TM Standard, MIFARE 4K, MIFARE Ultralight, MIFARE Ultralight C, MIFARE DESFire®, MIFARE DESFire EV1 ISO 14443B Smartcard ISO14443, SRI4K, SRI512 ISO 15693 SIC5600, ICODE-SLI-L, ICODE-SLIS Read payware and paypass and E-passport ISO7816 T=CL Supported NFC TAG 1~4 supported Felica READ UID Frequency 13.56MHz Standard Read Range Mifare: 1~3 cm ISO 15693: 2~4 cm Transponder Read / Write OS Support Windows 10 Interface USB HID (Cable Length: 60cm) Dimensions 130 x 35 x 40 mm Operating Temperature 0°C ~ 60°C
