crawler crane / boom / telescopic / lattice
GTC-800

Add to MyDirectIndustry favorites
Compare this product
crawler crane / boom / telescopic / lattice crawler crane / boom / telescopic / lattice - GTC-800
{{requestButtons}}

Characteristics

  • Configuration:

    crawler

  • Structure:

    boom, telescopic, lattice

  • Operating environment:

    for construction

  • Other characteristics:

    hydraulic, compact, diesel-powered, lifting, for heavy-duty applications

  • Lift capacity:

    80 t (88 us ton)

  • Working height:

    Min.: 11.5 m (37'08")

    Max.: 43 m (141'00")

Description

The versatile combination of heavy duty telescopic booms, hydraulically extendable crawlers, and extremely compact dimensions allow MANTIS cranes to often get closer to a job than bulkier, fixed length lattice boom crawler cranes or rough terrains that must deploy outriggers to achieve full lift capacity. These features coupled with 360° pick and carry capabilities and a variety of productivity improving attachments make the TADANO MANTIS telescopic boom crawler crane the most versatile piece of equipment on the jobsite.


Max. Lifting Capacity
80 t
Boom
11.5 m - 43 m
Boom extension
2.5 m / 10.1 m / 17.7 m
Max. Sheave height
63 m
Max. radius
55 m
Engine

Cummins QSB6.7

231 kW (314 PS)
Dimensions

Length: 14.61 m
Width: 3.49 m
Height: 3.35 m
