crawler crane / boom / telescopic / lattice

Add to MyDirectIndustry favorites
Compare this product Don’t compare this product
crawler crane crawler crane - GTC-600


  • Configuration:


  • Structure:

    boom, telescopic, lattice

  • Operating environment:

    for construction

  • Other characteristics:

    hydraulic, compact, diesel-powered, with counterweight, lifting, for heavy-duty applications

  • Lift capacity:

    60 t (66 us ton)

  • Working height:

    Max.: 36 m (118'01")

    Min.: 11.5 m (37'08")


The versatile combination of heavy duty telescopic booms, hydraulically extendable crawlers, and extremely compact dimensions allow MANTIS cranes to often get closer to a job than bulkier, fixed length lattice boom crawler cranes or rough terrains that must deploy outriggers to achieve full lift capacity. These features coupled with 360° pick and carry capabilities and a variety of productivity improving attachments make the TADANO MANTIS telescopic boom crawler crane the most versatile piece of equipment on the jobsite.

Max. Lifting Capacity
60 t
11.5 m - 36 m
Boom extension
2.5 m / 10.1 m / 17.7 m
Max. Sheave height
56 m
Max. radius
50 m

Cummins QSB6.7
231 kW (314 PS)

Length: 14.61 m
Width: 3.27 m
Height: 3.27 m
