Machine safety system HaloProtect™

Overview
HaloProtect™ is a secondary guarding solution for scissor lifts and boom platforms (MEWPs) designed to minimise asset damage during contact events and protect operators from crushing or entrapment caused by machine movement. Ribbon switches embedded in the bumper detect contact during drive or elevate operations and immediately stop the machine.

Operator Secondary Guarding (Overwatch)
The Overwatch subsystem uses a LIDAR sensor mounted on the control box side to monitor the operator's position relative to the controls. In-use algorithms evaluate operator stance and proximity and trigger a machine cut-out when required to prevent hazardous movement.

Product components and related products

• Ribbon Switches: pressure-sensitive ribbon switches with momentary, normally-open contacts, available in several profiles and mounted inside bumpers to detect contact events.
• Sensing Edges: safety edges providing reliable contact detection, offered in multiple sizes to suit different applications.
• Safety Mats: presence-detection mats that stop machinery instantly to protect personnel.
• Safety Bumpers: impact-detecting bumpers that stop movement and reduce force to protect people and equipment.
• Dado Panic: a simple emergency alert device activated with a single press.
• Control Units: fail-safe control units that integrate sensing products into compliant safety systems.

HaloProtect™ by TapeSwitch
HaloProtect™ is supplied as a bespoke secondary guarding package engineered to fit any make or model of scissor lift or boom platform. It delivers coordinated asset protection and operator safeguarding and integrates with TapeSwitch control units and fail-safe safety architectures.

Technical specifications

• Product name / model: HaloProtect™
• Primary application: scissor lifts and boom platforms (MEWPs)
• Protection provided: asset protection during contact events; operator protection against crushing/entrapment
• Contact detection method: ribbon switches embedded in bumpers (activate on drive or elevate contact)
• Operator safeguarding: Overwatch LIDAR sensor mounted to control box; monitors operator position and executes machine cut-out
• System integration: compatible with TapeSwitch control units and fail-safe safety systems
• Installation: bespoke solution designed to fit any make or model of scissor lift or boom platform
• Multimedia: product explainer video available
