Specifications
Depth : 30 / 50 / 80 m
Thickness : 400 to 800 mm or 500 to 1800 mm
Width : from 2500 to 4200 mm
Cylinder capacity : 2 x 219 000 lbs at 350 b
Closing force at teeth : 2 x 125 000 lbs
Automatic or manual half turn
Special hydraulique filtration
Hydraulic winder for hoses : 164 ft, 230 ft, 262 ft.
Description
The best closing torque in he world and the highest closing force for the best performance.
Semi kelly, automaic half turn, verticality control for the best quality of slurry walls or diaphragmwalls or cut off.
