Data electrical cable 100033540

powerS/FTProbust

Installation cable STX 900 S/FTP 4x2xAWG23/1 PUR, Cat.7, green; 500 m Article name - CU-C STX900 SFTP 4x2x23/1 C7 PUR gn Description - STX 900 Shield - S/FTP Structure - 4x2xAWG23/ Length - 500 m Category - Cat.7 Colour - green Cable Sheath Material - PUR For best connections Telegärtner offers shielded SF/UTP Cat.5 and S/FTP Cat.7 cables with PVC- or PUR-jacket with extended temperature range up to 85°C. The assortment includes installation and connection cables for connections exposed to intensive contamination with protection class IP67. These cables offer outstanding transmission characteristics with high power reserves and optimum protection against ambient influences by the use of particularly robust jacket materials. In accordance with EN 50173-1 the designation S/FTP describes a cable with an individual pair shield of aluminium foil surrounded by a mesh as a total shield. These cables with LSZH sheath are mainly used in buildings to provide the horizontal cabling infrastructure.Other cables with cable sheaths such as PE or PUR are installed for applications with higher ambient demands or special mechanical application conditions. Cables with flexible wires are used as raw material for assemblies or in installations with a low range. S/FTP cables have very slight runtime differences between the pairs and are ideally suitable for transferring very high data rates.
