Medical tray sealing machine MIZAR MED FCH-72M

linear arrayautomatic

Sealing machine for PETG blisters with TYVEK for the medical and pharmaceutical Traysealer machine for blister. Requirements for packaging medical products. Syringes, dental implants, surgical supplies, laboratory supplies, diagnostic tools, disposable products. The sealing of the blisters with Tyvek or medical paper is carried out by hot welding using multiple sealing plates thermo-controlled by certified probes (+ / - 1 degree) The insertion and positioning of the product to be sealed will take place manually, the closing of the drawer can be manual or automatic. At the end of the cycle the drawer will open automatically allowing quick removal of the sealed product. The electronic control of the equipment will take place via a PLC system, with set-up pages for several different work cycles. The equipment will be equipped with a switch for remote assistance and cloud transmission of machine parameters. Furthermore, a system is integrated into it Certified firewall. Industry 4.0 The equipment calibration service complies with the requirements of the UNI CEI EN ISO/IEC 17025 standard and guarantees the traceability of the measurements to the International System. Technical data: • Dimension:L.850 P. 650 H. 1350 mm • Max product dimensions: 0000x000x00 mm • Max number of products: 10/ 12 Pcs. • Maximum sealing temperature: 250 degrees • Mold change: YES (quick connector) • Power supply:220V - 2200 WAT • Pneumatic supply:5 - 7 Bar (10mm tube) • Weight:160.00 kg
