Reliable machine for easy solo operation, 17,500 p/h production capacity, 5-size conversion, efficient utilities for low costs.
Get more from less
• Reliable machine, simple for one person to operate
• Production capacity up to 17,500 p/h gives low unit cost
• Easy conversion between 5 sizes
• Highly efficient use of utilities enables a low operating cost and a good environmental performance
Features
Quality splicing
Enables correct, repeatable splicing of longitudinal strip reels, and at the same time makes the operation less labour intensive. The reels are exchanged approximately every 1.45 hours.
It’s never been easier to operate
The production is easily managed through a Tetra Pak Operator Panel (TPOP) system on the ground level. All major functions can be initiated and supervised - from production preparation to the Cleaning in Place (CIP) function.
Operational control and performance analysis
The packaging line monitoring system (PLMS) enables tracking of production performance, such as possible stop reasons, efficiencies, waste levels.
Long production runs raise efficiency
Each Tetra Pak A1 unit holds a jumbo reel of packaging material with sufficient supply for almost two hours of production at the higher speed, and about three hours at the lower speed. A jumbo reel holds sufficient material for up to 36,000 packages.
Neat seal between reels
The splicing unit heats and pressurises the packaging material to automatically make a neat seal between one reel and the next, so package production can continue uninterrupted.
