Meat brine injector machine IMAX 420

for fish

For the IMAX walking beam injectors, the meat is transported through the machine via a transport rake. This follows a flat elliptic curve. While the needles are outside the product, the rake lifts out of the transport bed and moves forward. In the controller, this product advance can be set to 50 mm or 100 mm. The bigger advance allows the largest transport capacity of the injector with a wide puncture pattern. Although the shorter 50 mm advance halves the capacity, but it provides a stitch pattern that is twice as narrow, which can bring technological advantages when injecting. Thus, the short advance is often used to achieve a high injection rate for products or to ensure perfect brine distribution with very low pressure. The transport rake is made entirely of stainless steel and thus extremely robust and hygienic. The IMAX rake injectors are available in three sizes from 420 mm to 620 mm pan width.
