Pad printing machine with hermetic ink cup AIR

semi-automaticmonochromecolor

Economical and very practical electro-pneumatic pad printing machine for 1-colour or multi-colour pad printing (part registration). Characteristics: 1 Colour | Ink/doctoring cup Ø90mm Quick change system of the ink/doctoring cup/cliché set. Digital piece counter Technical Data: Cycle: 1 Cycle or Automatic Workpiece counter: Yes, sequential Speed adjustment: Yes, Flow Controller Speed: Up to 2500 p/h Variable pad stroke: 30 - 100 mm in cliché and workpiece (independent) Maximum pad height: 95 mm Pressing force: 750 N Drive: Electro-pneumatic Control: Manual selector Control voltage: DC 24V Power supply: 230V - 50/60 Hz Power consumption: 2 A Compressed air: Dry and filtered 5-6 bar Air consumption: 75 l/min Dimensions: L 800 x W 200 x H 800 L 800 x W 200 x H 800mm Weight: 35 Kg Quality: Designed for industry according to European standards. Parts machined in our machining centres Laser-cut and CNC bent structure Original pneumatics from leading brands Non-contact actuator position sensors Easy to operate and quick ink cup changes. 100% Made in Spain.
