Color display module LM13232BCW-1

LCD/ISTNgraphicLED

We are TOPWAY, a professional manufacture for industrial LCD Module with many years experience, just as Medical, Audio, POS, Power Meter, communications equipment etc. Our renowned customers include Toshiba Tech, Emerson, GE...etc. We have character (up to 4 lines X 40), graphic(up to 5.7"/320X240) and TFT colour (3.2" to 15") modules. ★TOPWAY is a professional industrial LCD module manufacturer and solutions provider. For semi-custom or full-custom products, please contact us for further information and options. • - Resolution: 128*32 • - Interface: Serial(SPI-4wire) • - Viewing Direction: 6H • - Voltage: 3.3V • - LCD Display Mode : FSTN, Positive, Transflective • - Operating Temperature: -20 ~ +70°C • -Storage Temperature: -30 ~ +80°C • - Active Area: 53mm*15.5mm • - Outline: 58.8mm*26.3mm*9.8mm • - Backlight Type: LEDs TFT LCD Module A TFT LCD has a liquid crystal layer between a glass substrate formed with TFTs and transparent pixel electrodes and another glass substrate with a color filter (RGB) and transparent counter electrodes. Each pixel in an active matrix is paired with a transistor that includes capacitor which gives each sub-pixel the ability to retain its charge, instead of requiring an electrical charge sent each time it needed to be changed. This means that TFT LCD displays are more responsive.
