Metal cable entry plate MB 5/11
IP66IP67

metal cable entry plate
metal cable entry plate
metal cable entry plate
metal cable entry plate
metal cable entry plate
metal cable entry plate
Add to favorites
Compare this product


Characteristics

Specifications
IP66, IP67, metal
Cable diameter

Min.: 5 mm
(0.2 in)

Max.: 30 mm
(1.18 in)

Description

Provides very high protection against dust and water New design which gives excellent IP protection also when cables are bent effectly Flame resistant alternatives available Gland plates MC 3/7, MC 25/27, MC 35/37 and MB 5/11 are metal reinforced cable gland plates with IP66/67 classification. All types have a new design which gives excellent protection for separate cables when cables are bended effectly. The design gives absolute protection against dust and strong jets of water and even immersion between 0,15-1 m. MB 5/11 will lead through and seal cables as follows: 5-7 mm - - 4 pcs 7-10 mm - - 3 pcs 10-14 mm - - 2 pcs 15-30 mm - - 2 pcs
