Silicone rubber sheet MAGNETSIL (SMD)
food gradefor high temperaturesoil resistant

Silicone rubber sheet - MAGNETSIL (SMD) - Trelleborg Sheeting and Matting - food grade / for high temperatures / oil resistant
Silicone rubber sheet - MAGNETSIL (SMD) - Trelleborg Sheeting and Matting - food grade / for high temperatures / oil resistant
Silicone rubber sheet - MAGNETSIL (SMD) - Trelleborg Sheeting and Matting - food grade / for high temperatures / oil resistant - image - 2
Silicone rubber sheet - MAGNETSIL (SMD) - Trelleborg Sheeting and Matting - food grade / for high temperatures / oil resistant - image - 3
Add to favorites
Compare this product

Characteristics

Material
silicone
Other characteristics
oil resistant, for high temperatures, food grade
Thickness

Min.: 0.8 mm
(0.031 in)

Max.: 6.5 mm
(0.256 in)

Density

Min.: 1,300 kg/m³
(81 lb/ft³)

Max.: 1,400 kg/m³
(87 lb/ft³)

Working temperature

Min.: -60 °C
(-76 °F)

Max.: 230 °C
(446 °F)

Description

Meeting European Regulation (EC) 1935/2005 Tacum-free Features Food grade silicone containing an additive visible to metal detector equipment. Any loose fragment or eroded particle from the gasket can be detected easily by the scanners fitted along the food processing line. Volume resistivity > 1,1 x 10^12 Ω·m Surface resistivity > 3,2 x 10^13 Ω Detection test: SMD’s Samples run through metal detector (42 m/min). Result is converted to ferrous ball equivalent, 2,2 mm. SMD particles placed in food stuff tray is detected by X-Ray and displayed. For more detail ask to your local contact report nº SMD-X 201907 Applications Gaskets or washers cutting and manufacturing of pieces for general industrial applications in contact with: - foodstuffs - water - detergents - diluted acids - strong non oxidant acids Advantages Talcum-free, clean surface free of dust Time saver for cleaning and adhesive process Very good resistance to ozone, UV light, weathering and ageing Excellent temperature resistance (-60/+230ºC) Good ratio quality/price Benefits Performance Legality Food safety Hygiene, cleanliness Long life Recommandations Always follow manufacturer warnings and instructions when using any cleaning product.
