High-performance plasma marking unit TruMark 6030

high-precision

Overview The TruMark 6030 is an industrial short‑pulse marking laser for engraving, ablation, marking and annealing. It combines high average power with excellent beam quality and supports 3D marking via TruTops Mark 3D, enabling marking on inclined and curved surfaces.

Key benefits

• Up to 25% shorter process times due to higher available average power and increased pulse repetition frequencies.
• Precise, repeatable output thanks to integrated power regulation.
• Fast integration with numerous interfaces, removable connection cable and 19" plug‑in supply unit.
• Industrial‑grade design with high‑performance optical components for continuous production use.
• Flexible 3D marking with TruTops Mark 3D for sloped and curved surfaces.
• Linear power adjustment across the full frequency range for process scalability.

Applications

• Surface structuring (e.g., conrod structuring to improve tribological properties).
• Paint/coating ablation with short, powerful pulses.
• Permanently marking consumer or industrial goods (e.g., cookware, sanitary fittings) with high‑contrast marks.
• Marking on the fly for high‑throughput production of moving parts.

Software TruTops Mark 3D: 3D marking software with a 3D CAD editor to prepare workpieces and generate 3D marking data. VisionLine image‑processing options support component detection and code reading/verification.

Options & integration

• Extended marking volumes and alternative head variants.
• Longer connection cables (4 m → 6 m) and supply unit with IP54 option.
• Extended processing‑head temperature range (operation up to 45 °C).
• Fieldbus compatibility: Profibus, Profinet, EtherCAT, Ethernet/IP.
• NAVIGATOR module for assisted parameter selection, remote services and external exhaust options.

Technical specifications

• Model: TruMark 6030
• Beam quality (M²): < 1.3
• Wavelength: 1030 nm
• Pulse repetition frequency: 40 kHz - 200 kHz
• Minimum focal diameter: 50 μm
• Max. marking volume: 330 mm x 330 mm x 100 mm
• Max. text field: 330 mm x 330 mm @ f=650 mm
• Laser head dimensions (W x H x D): 156 mm x 214 mm x 435 mm
• Supply unit dimensions (W x H x D): 446 mm x 222 mm x 495 mm
• Ambient temperature (installation): 15 °C - 40/45 °C
