Built-in enclosure EG-VA805526/112-0632/3GD
rectangularplasticPS

Built-in enclosure - EG-VA805526/112-0632/3GD - TURCK - rectangular / plastic / PS

Built-in enclosure - EG-VA805526/112-0632/3GD - TURCK - rectangular / plastic / PS - image - 2

Add to favorites

Compare this product

Go to the TURCK website for more information

Characteristics

Construction: built-in
Configuration: rectangular
Material: plastic, PS, PE, stainless steel
Application: switch
Other characteristics: equipped, protection, input
Width: 800 mm
(31.5 in)
Height: 550 mm
(21.654 in)
Depth: 260 mm
(10.24 in)

Description

Stainless steel quality 1.4404 (AISI 316L) With inspection window Receptacle plate equipped with plastic cable glands (4 × M25 power supply, 4 × M20 Ex i bus, 108 × M20 Ex i I/O signals) and 1 × M20 breather/drainer Additional installation of 2 × AC/DC QUINT-PS power supply units, 2 × fiber optic coupler OC11Ex/2G.2 incl. wiring of the RS485IS connections with D9T-RS485IS and Ex e terminals (2 × UT10, 2 × UT10-BU, 2 × UT10-PE) for connecting the supply voltage Stainless steel housing with built-in module rack MT24-3G Country of origin - DE Weight - 39000 g Technical Data Product series - excom Device type - Housing Dimensions (W x L x H) - 800 x 550 x 260 mm Module rack - MT24-3G Input voltage - 115/230 VAC Coupler/converter/switch - Fiber optic coupler
