Spool pneumatic directional control valve DCC seriespneumatically-operated3/2-waynormally closed
Add to favorites
Compare this product
Characteristics
- Type
- spool
- Actuating method
- pneumatically-operated
- Ports/positions
- 3/2-way
- Function
- normally closed, normally open
- Other characteristics
- aluminium, spring-return, compact, brass, cartridge, IP65
- Operating pressure
Min.: 2 bar
(29.01 psi)Max.: 10 bar
(145.04 psi)- Flow rate
1,200 l/min, 3,500 l/min
(317 us gal/min, 924.6 us gal/min)
Description
Port Size: - In/Out - 1/4" BSP & Exhaust - 1/4" BSP
Media: - Compressed Air, Filtered & Lubricated
Ambient/Medium Température: - 5°- 60° C
Materials of Construction: - Aluminium, Nitrile, Brass, Polymer
> - Coil Width: 26 mm
> - Coil Bore: 10 mm
> - Voltage (V) + 10%: AC (50Hz, 60Hz) - 24V, 110V, 230V DC 12V, 24V
> - Power Consumption: AC-6W, DC-5W
> - Duty Cycle: Continuous
> - Class of Insulation: Class H
Features
Cartridge Type design for Long life
Single and Manifold Mounting
Lubrication not essential
Low Power Consumption
Wide range of coil voltages
Manual Override
Fast responce time at maximum 1500 cycle/ min
1 million Cycle tested
