Nickel-plated brass cable gland SKINTOP® MS-M
IP68IP69strain relief

Nickel-plated brass cable gland - SKINTOP® MS-M - U.I. Lapp GmbH - IP68 / IP69 / strain relief
Nickel-plated brass cable gland - SKINTOP® MS-M - U.I. Lapp GmbH - IP68 / IP69 / strain relief
Nickel-plated brass cable gland - SKINTOP® MS-M - U.I. Lapp GmbH - IP68 / IP69 / strain relief - image - 2
Add to favorites
Compare this product

Characteristics

Material
nickel-plated brass
Protection level
IP68, IP69
Other characteristics
strain relief, for the chemical industry
Cable diameter

Max.: 98 mm
(3.86 in)

Min.: 3.8 mm
(0.15 in)

Operating temperature

Max.: 100 °C
(212 °F)

Min.: -40 °C
(-40 °F)

Description

SKINTOP® MS-M, brass cable gland for cable diameters up to 98mm, in areas where mechanical and chemical stability are critical SKINTOP® MS-M sizes 75 x 1.5 to 110 x 2 with innovative double lamella gasket for easier assembling of cables with large diameters. Now with IP69 approval! Proven to withstand the most demanding cleaning procedures for industrial machinery with high-pressure cleaners and hot water!
