The windows-based PC control (with industrial PC - as standard) guarantees an operator-friendly handling of the welding machine
Freely selectable tool places
Profile identification for different profile cross-sections for an automatic process
Turning station not possible
Main Power Voltage: 400 VAC / 400 VAC
Current @ 440V: 16 A / 16 A
Air Pressure: 101 psi / 7 bar
Power Output: 4.7 HP / 3.5 kW
Machine Weight: 1,742 lbs. / 790 kg
Profile Height (min): 1.18″ / 30 mm
Profile Height (max): 7.87″ / 200 mm
Profile Width (min): 1.18″ / 30 mm
Profile Width (max): 3.14″ / 80 mm
Frame Outside Width (max): Unlimited / Unlimited
Frame Outside Width (min): 10.63″ / 270 mm
x2 Grooving or cutting knives (1 top & 1 bottom)
x2 Inside cleaning knives (1 top & 1 bottom)
x2 Vertical milling/drilling units (1 top & 1 bottom)
x1 Disc cutting unit
Options:
Profile identification
Horizontal knife cutting unit
Vertical knife cutting unit
Milling/drilling unit for the machining of radii
Inside cleaning units for oblique inner corners and curves
