IR photovoltaic detection module IC0 series

InAsSbindustrialexplosion detection

IC03110-01 is a detection module featuring an uncooled photovoltaic IR detector chip based on an InAsSb heterostructure, integrated with an ASIC-type (application-specific integrated circuit), transimpedance amplifier. This module has a TO39 cap featuring a 3 deg. wedged, zinc selenide, anti-reflection coated window. Features Spectral range: 2.0 to 5.6 μm RoHS-compliant III-V material Front-side illuminated ASIC-type electronics Programmable gain DC coupling (AC coupling on request) Compact, surface-mount type package Long-term stability and reliability High ambient operating and storage temperature Low power consumption Possibility of mounting optical filter Applications Contactless temperature measurement: railway transport, industrial and laboratory processes monitoring Flame and explosion detection Threat warning systems Heat-seeking, thermal signature detection Dentistry Gas detection, monitoring and analysis: CH4, C2H2, CH2O, HCl, NH3, SO2, C2H6, CO, CO2, NOx Breath analysis: C2H6, CH2O, NH3, NO, OCS Gas leak detection Combustion process control Non-destructive material testing
