Wheeled inspection robot IPIDRO

compactminiatureremote-controlled

Overview
The IPIDRO is a compact magnetic crawler for remote visual inspection of hard-to-reach ferromagnetic components. Controlled via the VUnit and integrated in viZaar’s Full HD platform, it replaces push rods and rigid tools to allow safer, faster and more predictable inspections from a distance.

Applications
Suitable for metallic pipelines, heat exchangers, cooling circuits, process pipes, HVAC ducts, industrial boilers and chimneys — any component made of steel or other ferromagnetic materials. IPIDRO helps detect corrosion, leaks, deposits and obstructions early and supports condition-based maintenance in chemical plants, oil & gas, power generation and utilities.

Key features

• Heat-optimized anodized aluminum housing (Ø 48 mm, 130 mm length)
• Fixed front-view camera (DOV 0°) with wide-angle lens (FOV 145°)
• Uncompressed Full HD resolution (1920 × 1080 px) and lossless PNG inspection images
• High light sensitivity down to 0.003 lux
• Four dimmable high-performance LEDs for illumination
• Motorized remote focus adjustable from 20 mm to infinity
• Magnetic wheels with reinforced polyurethane coating and differential steering for maximum traction, including overhead/inverted inspections
• Radial pipe inspection from DN 300; flexible connector for navigation on steep inclines
• Fixed 20 m umbilical cable with meter markings
• Constant travel speed up to 3 m/min for precise positioning
• Lightweight design — total weight approx. 950 g including supply cable
• Operation range: -10 °C to +45 °C
• Part of viZaar Full HD platform; controlled via the VUnit
• Secure documentation: integrated comments, technical overlays, HDMI output, optional hardware-encrypted USB and internal memory lock
• Portable use with standard professional batteries (>8 hours) and seamless mains/battery switching

Built-in platform and workflow
IPIDRO integrates with viZaar’s Full HD inspection platform and is operated via the VUnit. The VUnit places controls and a Full HD display outside the inspection image using scroll wheels, joysticks and direct keys, streamlining operation, documentation and advanced post-processing workflows.

Technical specifications

• Model: IPIDRO
• Manufacturer / Brand: viZaar
• Housing: heat-optimized anodized aluminum
• Diameter: 48 mm
• Length: 130 mm
• Camera resolution: uncompressed Full HD 1920 × 1080 px
• Field of view (FOV): 145°
• Light sensitivity: up to 0.003 lux
• Illumination: 4 dimmable high-performance LEDs
• Focus: motorized remote focus, 20 mm to infinity
• Wheels: magnetic with reinforced polyurethane coating
• Drive: differential steering
• Pipe inspection: radial inspection from DN 300
• Connector: flexible connector for steep inclines
• Supply cable: fixed 20 m umbilical with meter markings
• Travel speed: up to 3 m/min
• Operating temperature range: -10 °C to +45 °C
• Total weight (including cable): approx. 950 g
• Battery operation: >8 hours with standard professional batteries (seamless mains/battery switching)
• Platform compatibility: viZaar Full HD platform, controlled via VUnit
• Documentation/output: uncompressed PNG images, Full HD video, HDMI output, integrated commenting, technical overlays, optional hardware-encrypted USB
