Porosity analysis software VGinLINE

visualizationCADmeasurement

VGinLINE inspects your parts automatically and non-destructively with industrial computed tomography (CT). It’s simple to set up and works with almost every CT system on the market – right out of the box. Inspect your parts automatically or semi-automatically with a recurring analysis pattern. Therefore VGinLINE Complete offers all relevant features of VGSTUDIO MAX, i.e., coordinate measurement, wall thickness analysis, nominal/actual comparison, defect detection (pores, voids, inclusions), fiber orientation analysis, and foam/powder analysis. With VGinLINE, you stay flexible by easily reconfigure VGinLINE yourself. VGinLINE can work with almost any format. No CT scanner? VGinLINE also supports point clouds and meshes in addition to voxel data. VGinLINE is based on a simple idea: Monitor directories for incoming CT data sets. With jobs, you define what VGinLINE does with CT data sets. Use VGSTUDIO MAX to create macros and templates while drawing from the full scope of available analyses.* You can build a new job from scratch by combining macros and templates, or duplicate and modify an existing job. In VGinLINE, you can include if-then statements in your jobs if necessary. The dashboard informs you about the status of your inspections and the results for every part in real-time. *Depends on license
