Compact programmable logic controller PLC20X

inputsdigital outputsEthernet

The PLC200 and PLC201 Programmable Logic Controllers are the newest PLCs WEG. This family of controllers was developed to serve small to medium-sized applications, it stands out for its extremely compact and powerful hardware, offering flexibility and modularity for expansions. Fully programmable through the WPS® platform. High-tech - Excellent cost-benefit Extremely compact and modular design; Powerful ARM cortex M7 de 400 MHz processor; Flash Memory / Retentive data RAM / Non-Retentive data RAM - 1MB / 4KB / 128KB Digital Inputs / Digital Outputs: 8 / 4 (PNP); 4 dual-channel high-speed inputs up to 150kHz; Support for Ethernet Protocol: Modbus TCP / Ethernet-IP(Adapter); Support for Serial: ¹Modbus RTU ou ²CANopen; IoT Protocols(MQTT: Publisher/Subscriber); USB port for Programming; 1 x Ethernet port; 1 x ¹RS485 or ²CAN port; Supports up to 08 local expansions. ¹ Support for the Modbus RTU protocol with the mode PLC200 ² Support for the CANopen protocol with the model PLC201 Flexibility above all Developed to be a PLC os fast integration to the factory environment and easy expansion, PLC200 shares the same expansion cards used in the line of RUW100, PLC500 e PLC410. Thus, you purchase a card and can use it in different WEG products, that is FLEXIBILITY. All expansions are made through the Plug and Play concept, Simple, Fast and Efficient.
