Single-axis accelerometer 746
piezoelectrichigh-sensitivityIP68

single-axis accelerometer
single-axis accelerometer
single-axis accelerometer
single-axis accelerometer
Add to favorites
Compare this product


Characteristics

Number of axes
single-axis
Technology
piezoelectric
Other characteristics
high-sensitivity, IP68, for general purposes, underwater
Frequency

Min.: 1 Hz

Max.: 15,000 Hz

Description

Top exit, underwater accelerometer, 10ft integral J6 cable, titanium case, case isolated, 100 mV/g Features Hermetically sealed Titanium case 650 psi pressure rating IP68 rated integral cabling for submerged applications Included accessories SF1 mounting stud Specifications PARAMETER VALUE Sensor output Dynamic vibration (IEPE) Sensitivity 100 mV/g Sensitivity tolerance ±5 % Frequency response 1 Hz - 15,000 Hz Mounting Thread 10-32 tapped hole Connector style Integral cable Connector orientation Top exit Full-scale range 80 g peak Resonance frequency 30 kHz Temperature range –50°C to +80°C Weight 45 grams Hazardous area approvals Non-approved
