Touch screen panel PC IPCH0846F2-SN35L0-CB0M0ATFT LCDLED backlight8.4"
Add to favorites
Compare this product
Characteristics
- Screen type
- TFT LCD, LED backlight, touch screen
- Display size
- 8.4"
- Resolution
- 800 x 600
- Processor
- Intel® Celeron® J6412, Intel® Elkhart lake SoC
- Applications
- industrial
- Other characteristics
- fanless, IP65, IP66, IP69K, IP67
Description
Fanless Panel PC IP65 front Chassis(Option: IP66/IP69K front), 8.4" LCD monitor, 800 x 600, LED 350 nits,Intel®Celeron J6412
Features
Modularize mechanical design provides flexible product configuration and easy maintenance
Optional build-in touch screen for interactive application
Intel®Celeron J6412 processor
Intel® Elkhart Lake
Support DDR4-2666/2933/3200MHz, Max. Capacity 32GB
I/O: 2 x HDMI, 3 x USB 3.0, 3 x USB 2.0, 2 x LAN, 1 x Line-out
Security support TPM 2.0 onboard IC
Standard IP66/IP67 models I/O: 1 x HDMI, 2 x USB, 1 x LAN.
Optional connector type: M12 Metal connectors, MIL-38999, MIL-26482 series connectors
