Centrifugal rotor crusher WRC 240 Xmobilefor hardstonehigh-capacity
Add to favorites
Compare this product
Characteristics
- Technology
- centrifugal rotor
- Mobility
- mobile
- Other characteristics
- for hardstone, high-capacity, stone, for building materials
- Capacity
Min.: 0 kg/h
(0 lb/h)Max.: 600,000 kg/h
(1,322,773.6 lb/h)
Description
Overview
Applications
Technical features
Operator interface & digital assistance
Serviceability & productivity
- In-situ rock crushing and homogeneous mixing unit based on the WR 240 X platform, designed for processing unbound materials and less compact soils containing coarse stones.
- Capable of crushing rocks, hard cores, concrete fragments and cobbles with production rates up to 600 t/h and a machine advance rate of approx. 7 m/min.
Applications
- Soil improvement and agricultural cultivation (soil conditioning).
- Road construction: crushing of concrete fragments and hard cores, soil stabilisation and maintenance of mine roads.
- Soil treatment where in-situ crushing and homogenisation of coarse inclusions is required.
Technical features
- Reinforced and optimised chassis tailored to primary heavy-duty applications.
- Crushing unit composed of material infeed flap, variable and fixed crushing stages, crushing & mixing rotor, and discharge grates with scraper plate.
- Special rotor transmission with active cooling; rotor speed approx. 250 rpm.
- Designed to process materials with uniaxial compressive strengths up to 200 MPa.
- Production capability up to 600 t/h (depending on material and site conditions).
Operator interface & digital assistance
- X-Tier man–machine interface (MMI) provides guided assistance for correct operation and improved in-situ crushing/mixing quality.
- MIX ASSIST digital components and WIRTGEN GROUP COPILOT enable process monitoring, recipe control and higher operational efficiency.
Serviceability & productivity
- Design focused on accessibility of wear parts and key drive elements to simplify service and reduce downtime.
- Digital assistance and optimised machine components contribute to predictable productivity and controlled operating costs per m².
