X-ray tube X-ray 50501

Wisman' s 50501 series is a highly popular and proven side window X-ray tube. Currently in use for many industrial applications, the 50501 series features an electron gun assembly packaged in a stainless steel lead-lined package with a choice of mounting flange. The package is filled with an Oxford Instruments designed cooling oil that maximizes heat dissipation. The package can be supplied with a high voltage well connector and a triax connector for the filament supply. The tube is to be operated in a positive anode mode with the cathode grounded. The standard exit window is 0.005 inch Beryllium. Applications XRF Inspection Mining and geology Densitrometry Thickness gauging Regulatory (RoHS/WEEE) Art and archeometry R&D
