Single-phase electric energy meter DLC-DSS150

panel-mountRS-485digital

DLC-DSS150 is a full digital two phase three wires watt-hour meter with advanced SMT production technology which is used to measure active energy of two phase. LCD display, with LED indicators for phase loss, no current and reverse. It can still display power even when power off (keep for more than 6 hours.), with RS485 communication port. Measure active energy for total and each phase. Digital pulse output. Full digital measurement with imported MCU. Power supply on both two phase. Any phase, in two phase three wires, has power, the meter can work well. At the same time, it has function for phase loss indicate. Communication port: RS485. 6+2 LCD display. The meter can be reset for 5 times in usage, after 5 times, it cannot be reset. Specification: •Working voltage: 70%～130% (rated voltage) •Rated current: 1.5(6)A 10(40)A 5(100)A 15(100)A •Accuracy: CL 1.0 •Rated frequency: 60Hz •Consumption: 10 years
