Core drilling drilling rig XY-5explorationrotaryhydraulic
Add to favorites
Compare this product
Characteristics
- Drilling type
- core drilling
- Function
- exploration
- Drilling unit
- rotary
- Other characteristics
- hydraulic
- Drilling diameter
Max.: 89 mm
(4 in)Min.: 50 mm
(2 in)- Drilling depth
Max.: 1,500 m
(4921'03" )Min.: 1,000 m
(3280'10" )- Overall length (working)
3,190 mm
(126 in)- Overall width (working)
1,495 mm
(59 in)- Overall heigth (working)
2,140 mm
(84 in)- Motor power
55 kW
(74.78 hp)
Description
XY-5 core Drilling Rig is suitable for conventional and slim-hole dlamond drilling in geological hydrogeological and coal field exploration. It can drill vertical and angle holes.
Main features
● High rotational speed of spindle and wide range lf speed. It possesses reverse rotation.
● Built-in hydraulic brake. Smooth and even lowering of drill string, simple operation, lasting service life of brake bands.
● With its wide base frame and low center of gravity, the drill stability is ensured.
● It has conventional and large inner dia. Spindles for user choosing.
● The special slide valve is provided in the hydraulic system for the breakou tool.
