Crawler drilling rig YGL-C150M

core drillingmultifunctionrotary

Application The Drilling Rig Model YGL-C150M, which is a full hydraulic top drive impact power head crawler drilling rig. It applies to construction of big tonnage stress anchoring hole, the grouting reinforcing hole drilling and the drain hole. And the drilling holes of landslide preventing and the treatment engineering of rock collapse, also can used in boring the GSHPs hole, blast hole. The drilling rig is multi-angle、multidirectional drilling machine. The drilling rig has a variety of drilling methods ,can effectively resolve the problem of difficulty of drilling in lose cover strata, gravel layers ,broken rock strata ,it can be adaptable in different terrain, specially for complex drill work place, so it should have a very widely usage. Main Features ● Drilling rig has been configured top hydraulic rotary power head impact which is Germany imported，faster speed of borehole, higher efficiency.。 ● Rotary power head is used itself power to achieve impact, no need deploy air compressor. ● The rig working very effectively for it has large scale range of angle. ● Rig’s power head can be lateral move to conceded center position, convenient for construction. ● Zoning scheme of rig’s hydraulic optional control handle，Convenient operation and effectively prevent the disoperation.
