Cylindrical gear wheel MHGH01502011-DIN6
helical-toothedshaftedcarbon steel

Cylindrical gear wheel - MHGH01502011-DIN6 - Yuan Yi Chang Machinery Co., Ltd. (YYC) - helical-toothed / shafted / carbon steel
Cylindrical gear wheel - MHGH01502011-DIN6 - Yuan Yi Chang Machinery Co., Ltd. (YYC) - helical-toothed / shafted / carbon steel
Cylindrical gear wheel - MHGH01502011-DIN6 - Yuan Yi Chang Machinery Co., Ltd. (YYC) - helical-toothed / shafted / carbon steel - image - 2
Add to favorites
Compare this product
Go to the Yuan Yi Chang Machinery Co., Ltd. (YYC) website for more information

Characteristics

Type
cylindrical
Teeth
helical-toothed
Configuration
shafted
Material
carbon steel
Applications
industrial, for gear wheels
Other characteristics
precision, ground, machined

Description

Overview
  • Helical ground pinion MHGH01502011-DIN6 for industrial gear assemblies.
  • Material: SCM440. Induction hardened to HRC50-55; teeth induction-hardened and ground.


Technical data
  • Tooth profile: Helical (left-hand)
  • Module (M): 1.5
  • Number of teeth (Z): 20
  • Quality: DIN6
  • Pitch circle diameter (ød): 31.831 mm
  • Outside diameter (øD): 34.83 mm
  • ød2: 25 mm
  • Hole diameter (ød1): 11 mm
  • Total width (W2): 22 mm; W1: 20 mm
  • Keyway: Yes
  • Helix angle (β): 19°31'42" (left-hand)
  • Hardness after induction hardening: HRC50-55
  • Weight: 0.10 kg


Applications / Key specifications
  • Product code: MHGH01502011-DIN6
  • Suitable for compact industrial gear trains requiring DIN6 precision
  • Max feed force: 4.71 kN (range ≦10 kN)
  • Delivered with finished bore and keyway, ready for assembly
  • Ideal where hardened, ground teeth and precise helix are required


Unit : mm
