Infrared laser cutting machine XDQJ-1200(II)for granitefor marbleblocks
Add to favorites
Compare this product
Characteristics
- Technology
- infrared laser
- Material
- for marble, for granite
- Product handled
- blocks
- Control type
- PLC-controlled
- Applications
- for industrial applications
- Configuration
- bridge
- Other characteristics
- automatic
- Overall length
7,300 mm
(287 in)- Overall width
5,000 mm
(197 in)- Height
5,000 mm
(197 in)- Weight
7 t
(7.72 us ton)
Description
Diameter of Blade: Φ600 mm –Φ1200 mm
Size of Worktable: 3200mm×2000mm
Maximum Transverse and longitudinal cutting Distance: 3200mm
Maximum travel of cutter lifting : 750mm
Tilt Angle of worktable：0-83°
Cutting Thickness: 0-450mm
Power of Main Motor: 22kw
Water consumption：4m3/hour
Total Power: 27.9KW
This machine adopts infrared for tool setting and adopts the magnetic grid ruler to measure the goal value , the accuracy of size of processing slabs is higher than adopted encoder. also use hydraulic to transmit. it is controlled by the mini- computer(PLC system). this machine is mainly used for cutting and processing marble slabs, granite slabs, artificial stone slabs, quartz stone slabs. especially suitable for cutting large expensive slabs and thick slab craft material.
