Solar combiner box BHS-12/1 1500V
compactrectangularpolycarbonate

solar combiner box
solar combiner box
Add to favorites
Compare this product

Characteristics

Construction
compact
Configuration
rectangular
Material
polycarbonate
Application
for photovoltaic applications
Other characteristics
solar combiner
Protection level
IEC, IP65

Description

1500Vdc Solar Disconnect Combiner Box The most compact and cost-efficiency combiner for 1500V solar PV systems, thanks to the DC components including 2P fuse holders and UL98B, IEC60947 Standard disconnect. The 4 pole DC Disconnect up to 1500V at 250A. 1500V finger safe touch DC fuse holders for both positive and negative poles for over-current protection. 1500V DC surge protection type 2 to protect the DC strings from over-voltage. (type 1+2 for option) Customized solutions are available to meet specific needs of different solar systems. Features: *Rated for 1500VDC *UL98B listed and IEC 250A integrated disconnects *Up to 18 input circuits and customized solutions *Type 2 DC surge arrester and Type 1+2 for option *Finger safe touch fuse holder at 2P *NEMA4X, IP65 polycarbonate enclosure
