V-type conveyor belt

for the food industryfor the chemical industryfor the mining industry

Usage
Profiled conveyor belts are suitable for conveying powder, granular, small lump materials at gradients of no more than 40°, and can also convey packaged materials. Widely used in coal mines, power generation, chemical industries, grain handling, etc.

Characteristics
Pattern type: 八 shape, V shape, etc.

Structure
Structural illustration available (see product images).

Standard Specifications
Note: It can be customized according to customers’ requirements.

Cover Grades
In accordance with ISO 14890-2013 standard. The values will help to determine the appropriate cover compound for the application or for the materials carried. Reliable assessment of the behavior of the covers in service for wear and cut resistance cannot be determined from tensile strength and abrasion values alone.

Characteristics / technical specifications

• Suitable materials: powder, granular, small lump materials
• Maximum conveying gradient: no more than 40°
• Also suitable for conveying packaged materials
• Typical applications: coal mines, power generation, chemical industry, grain handling
• Pattern types available: 八 shape, V shape, etc.
• Standard for cover grades: ISO 14890-2013
• Product can be customized according to customer requirements
