Pneumatic actuator lineardouble-pistondouble-acting
Add to favorites
Compare this product
Characteristics
- Type
- pneumatic
- Movement
- linear
- Technology
- double-piston
- Configuration
- double-acting
- Material
- stainless steel
Description
Product Features:
High cycle dual piston stainless steel pneumatic actuator
Compact design, outer size of pneumatic actuator is the same as flange size connecting diaphragm and valve body
Suitable for combination assemble of multi-way body and multi valves
Air inlet is the upper side of actuator
Control air inlet can be installed by rotating 90°
Sealing o-ring between valve diaphragm and valve body
Flexible diaphragm suspension structure
Wrapped valve diaphrag
Cleansed and polished actuator suitable for sterilization
Technical Parameter:
Control Mode: Manual
Max. Working Pressure: DN25~50 10bar , DN65~100 8bar
Max. Working Temp.: 175℃
Diaphragm Material:EPDM,PTFE
Valve Body Material: Forged stainless Steel 1.4435 /316L, ASME/BPE forged stainless steel 1.4435/316L, other alloy
Connection: Welding, tri-clamp, flange, etc.
Bonnet suitable for: Two-way body, welding connection, T type body, multi way, bottom tank body, etc.
