H2S gas sensor module ZP150

NH3H2CO

ZP150 module is an odor detection module developed for pet odor detection application environment. ZP150 module adopts flat surface semiconductor gas sensor. The module has good sensitivity to volatile organic gases such as hydrogen sulfide, ammonia, alcohol，smoke of cigarette, formaldehyde, benzene, carbon monoxide, hydrogen, and essence &etc. The module has been aging, debugged, adjusted and calibrated. So it has good consistency and high sensitivity. And with UART digital output function, communication is simple and easy to use. Application Air cleaner, air quality monitor, smart cat litter box, smart pet house, pet deodorizer, etc Features High sensitivity Excellent long-term stability Calibrated before shipment long life High cost-effective Specifications Model No. - ZP150 DetectionGas - hydrogen sulfide ,ammonia, alcohol, smoke ofcigarette,formaldehyde,benzene,carbon monoxide,hydrogen, , essence &etc. Physical Interface - XH2.54-4P terminal sockets Measurement range - 0-5ppm Resolution - 0.05ppm Working Voltage - 5.0±0.2V DC (No voltage reverse connect protection) Output - UART(5V) Working Current - ≤70mA Warm-up Time - ≤3 min Operating Temperature - 0～50℃ Operating Humidity - ≤95％RH Storage Temperature - －20～60℃ Storage Humidity - ≤60％RH
