CONTRINEX analog proximity sensors

Length: 35 mm
Measuring range: 1.5 mm
Process temperature: -25 °C - 70 °C

Switching frequency max. - 5000 Hz Polarity - NPN Output - Normally Open (NO) Connection - PVC, 2 m, 3 wire Housing size [mm] - Ø 6.5 Housing material - Stainless-steel V2A Mounting - Embeddable Interface - Standard output

Length: 22 mm
Measuring range: 0.6 mm
Process temperature: -25 °C - 70 °C

Switching frequency max. - 5000 Hz Polarity - NPN Output - Normally Open (NO) Connection - PUR, 2 m, 3 wire Housing size [mm] - Ø 3 Housing material - Stainless-steel V2A Mounting - Embeddable Interface - Standard output

Length: 45 mm
Measuring range: 3 mm
Process temperature: -25 °C - 85 °C

Switching frequency max. - 1200 Hz Operating pressure [bar] - ≤ 100 bar Polarity - NPN Output - Normally Open (NO) Connection - PUR, 2 m, 3 wire Housing size [mm] - M8 Housing material - Stainless-steel V2A Mounting - Embeddable Interface ...

Length: 50 mm
Measuring range: 0 mm - 4 mm
Process temperature: -25 °C - 70 °C

... voltage - 15...30 Polarity - Analog Output - Voltage + Current Connection - PUR, 2 m, 3 wire Housing size [mm] - 8 x 8 (C8) Enclosure rating - IP 67 Housing material - Chrome-plated brass Temperature range - -25...+70°C Sensor ...

Length: 22 mm
Measuring range: 0.6 mm
Process temperature: -25 °C - 70 °C

... Housing size [mm] - Ø 3 Enclosure rating - IP 67 Housing material - Stainless-steel V2A Temperature range - -25...+70°C Sensor Height - 22 mm Mounting - Embeddable

Length: 12 mm
Measuring range: 0.8 mm
Process temperature: -25 °C - 70 °C

Switching frequency max. - 8000 Hz Operating pressure [bar] - ≤ 200 bar Polarity - NPN Output - Normally Open (NO) Connection - PUR, 2 m, 3 wire Housing size [mm] - Ø 3 Enclosure rating - IP 68 / IP 69K Housing material - Stainless-steel ...

Length: 25 mm
Measuring range: 0.8 mm
Process temperature: -25 °C - 120 °C

Switching frequency max. - 5000 Hz Polarity - NPN Output - Normally Open (NO) Connection - Silicone, 2 m, 3 wire Housing size [mm] - M5 Housing material - Stainless-steel V2A Mounting - Embeddable Interface - Standard output

Length: 60 mm
Measuring range: 2 mm
Process temperature: 0 °C - 140 °C

Switching frequency max. - 600 Hz Polarity - NPN Output - Normally Open (NO) Connection - Silicone, 2 m, 3 wire Housing material - Stainless-steel V2A Mounting - Embeddable Interface - Standard output

Length: 60 mm
Measuring range: 3 mm
Process temperature: -25 °C - 85 °C

... size [mm] - M12 Enclosure rating - IP 68 / IP 69K Housing material - Stainless-steel V2A Temperature range - -25...+85°C Sensor Height - 60 mm Mounting - Non-embeddable Interface - Standard output

Length: 64 mm
Measuring range: 3 mm - 5 mm
Process temperature: -25 °C - 85 °C

Switching frequency max. - 10 Hz Operating pressure [bar] - ≤ 40 bar Polarity - PNP Output - Normally Open (NO) Connection - M12 4-pin Housing size [mm] - M30 Housing material - Stainless-steel V2A Mounting - Non-embeddable Interface ...
