Telefone analógico

IP66para elevadorpara túnel

Introduction
The elevator Intercom system will be applied to elevator emergency or maintenance application. Also applicable for shipping center, bus terminal, car park center, tunnel construction, etc. Power supply: Centralized DC 12V or AC 110~220V AC.

Operating Instructions

• Master station call elevator phone: Pick up the master station handset, press the elevator phone number and speak to it. Press * to speak all elevator phone. Elevator phone will auto stop when master station hang up.
• Elevator phone call Master station: press call button or pick up hand, the phone will automatically call master station. Both master will ring. Elevator phone will auto stop when master station hang up.
• Master1 call Master2: Pick up the handset of the Master1, then press the other master station phone number, Master2 rings, speak to it.

Specification
Working Voltage: DC12V
Operating Current: ??300mA
Maximum Power Consumption: 2W
Noise Voltage: ??1OmV
Communication Distance: ??2000m
Ringing Level: ??7OdB

Working Condition
- Ambient Temperature: -40????60??
- Relative Humidity: 30%??95%
- Ambient Noise: 60 dB
- Line Number: double core line
- Description for the wire: single line resistance can't more than 50 Ohm.

Wire requirements
Require all connecting the kingdom line, multicore parallel lines can meet the general engineering requirements. When running line near strong power lines or in serious interference environments with mixed wiring, shielding measures should be adopted, keep distance and take more than 30 cm.

Certification

• EMC: EN50121 (Railway application - Electromagnetic Compatibility)
• EN55022: emissions
• EN55024: immunity
• Ingress Protection: GB4208-93 IP66
• FCC
• ITU-T Recommendations K21

Packing details

• 1 pcs in each inner CTN box; size: 43.3 x 27.6 x 19.1 cm; G.W: 4 kg
• 4 pcs in outer CTN box; size: 56.6 x 44.5 x 42 cm; G.W: 20.25 kg
• 20GP: 3000 PCS; 40GP: 6000 PCS; 40HQ: 7000 PCS

Documentation
Pdf available: 5way-intercome-with-123master (product PDF file).

Caractéristiques / spécifications techniques

• Modèle: Five way intercom with Master
• Alimentation: Centralized DC 12V or AC 110~220V AC
• Tension de fonctionnement: DC12V
• Courant de fonctionnement: approx. 300 mA (valeur source page: ??300mA)
• Consommation maximale: 2 W
• Tension de bruit: approx. 10 mV (valeur source page: ??1OmV)
• Distance de communication: approx. 2000 m (valeur source page: ??2000m)
• Niveau de sonnerie: approx. 70 dB (valeur source page: ??7OdB)
• Conditions de fonctionnement: Température ambiante -40 ~ 60°C (valeur source page contient caractères ambigus), humidité relative 30% ~ 95%
• Ligne: double core line; résistance d'une ligne ne doit pas dépasser 50 Ohm
• Indice de protection: IP66 (certification)
