Machines need control systems with the same level of sophistication, flexibility and fieldbus networking of large plants. Systems need compact devices able to incorporate functions such as PID algorithm, floating point, sequencing functions of a PLC and the flexibility of a PC. This is now possible without facing excessive costs and without using cumbersome equipment. This device has been termed a PAC. The Ascon's “Sigma microPAC”, is a small but powerful PAC sized to cover the applications for industries such as food and beverage, plastic and rubber, chemicals and pharmaceutics and for machines such as boilers, furnaces, kilns, chillers, autoclaves, plastic extruders, cold rooms. With the basic unit of the Sigma microPAC it is possible to control a process with: eight analogic variables from any type of transducer or sensor directly connected as inputs; four analogic outputs to command control valves or power controllers; eight digital inputs and eight digital outputs to manage interlocks, sequences and commands to pumps, shut-off valves. Expansion units for 32 DI + 32 DO fit applications requiring more sequencing of discrete signals. The 5 programming languages comply with IEC 61131-3 and are aided by the Ascon’s libraries with a large selection of function blocks. Processor is 32 bit, Flash Memory is 4Mbyte (2Mbyte for programming), RAM is 16Mb, 128 Kb retentive. Connectivity is by one RS 232/485 with Master/Slave Modbus RTU or ASCII, one RS 485 with Master/Slave Modbus RTU and one Ethernet port with Modbus TCP/IP. Advantages include being able to meet requirements that PLCs require extra components to do, reduce panel dimensions, lower hardware and development cost
|
|
|
|
|
|
Full PLC performance in a tiny package
The FX family includes four independent but fully mutually-compatible product lines:
FX3U
• Safe investment
• Tailored configurations
• Powerful positioning control
• Fast installation and configuration
• Integrated automation
• Outstanding value for money
FX2N
• 16 to 256 inputs and outputs
• High processing speed
• Ample program storage capacity
• Can be expanded with up to eight special-function modules
• User-friendly programming
• Integrated positioning controller
FX1N
• 14 to 128 inputs and outputs
• High processing speed
• Ample program storage capacity
• Integrated positioning controller
• Comprehensive range of special function for individual requirements
• Integrated PID controller
• Support for connection to open networks Integrated real-time clock
• User-friendly programming
• Analogue signal processing
FX1S
• 10 to 30 inputs and outputs
• High processing speed
• Ample program storage space and large device ranges
• Integrated positioning controller
• Serial communications options
• Analogue signal processing with optional expansion adapters
• User-friendly programming
• Expandable with adapters or display modules
|
|
The Saia®PCD product range reflects the values, characteristics and standards of Programmable Logic Controller (PLC). However, in their form, openness and functionality these products far exceed the traditional PLC. With Web and IT functions included, the Saia®PCD automation platforms is simply the best choice for every modern project.
All-in-one and robustness : Compact Saia®PCD are a safe investment for the automation of building, infrastructure, water, energy, logistics and machines.
With 38 on-board I/O, extendable with 4 modules taken out of our standard range of over 50 different I/O modules and a broad selection of communication protocols (TCP/IP, Modbus, Profibus, LON, Bacnet and many more) make the compact Saia®PCD automation platform an easy solution for smaller projects.
|
|
|
The VIPA system 100V is a Micro-PLC system programmable with Step®7 from Siemens or WinPLC7 - a programming tool from VIPA. With a compact design, system 100V provides a maximum expansion of up to 160 I/O points by plugging in expansion modules. These Micro-PLCs are especially suitable for use in smaller and cost-conscious applications.
|
|
AutoLog® 2000S
AutoLog® PLC is designed for large size projects where large quantity of I/Os are needed. Modular, freely selectable plug-in I/O modules are inserted into metal rack. CPU card and power is also inserted into same rack. CPU card doesn't have own I/O. P-model CPU has build-in power, so it can be used in small MR3 rack.
|
|
Compact PLC – The open and closed-loop control system
Compact PLCs are all-in-one devices that, even in their basic version are equipped with a comprehensive set of hardware and software functions and thus suitable for use in many control, regulating and measuring applications. Where the integrated functions do not suffice, the devices can be simply expanded either locally or via network.
The range includes:
* Compact PLC – PS4
* LE4 – local expansion units
* EM4 – distributed expansion units.
All the compact PLC are networkable and programmable via integrated fieldbus. The programming software applicable to all is Sucosoft S40, an easy-to-use programming package to IEC 61131-3.
|
|
Base Models with 10 to 14 I/O, Expandable to 256
Half the Size of Most PLCs
1-, 4-, 8-, 16-and 32-Bit Instructions
DIN Rail Mountable, No Rack Required
Built-in Integral LCD Display
High-level Network Access - Modbus TCP, DeviceNet and Profibus
Plug-In Modules for Analogue I/O, Thermocouples and Pt100 RTDs
|
|
|
The package-type SYSMAC CPM PLCs feature a space-saving design to contribute to integration in small machines and wiring panel downsizing.
|
|
It is now over 25 years since Mitsubishi Electric launched the first compact PLC on the European market. Since then Mitsubishi has become the world market leader in this sector, with over 8 million of its compact controller installations to its credit.
With their compact dimensions and low cost compact controllers have opened up new perspectives in industrial automation. Many applications for which automation was once not even an option can now benefit from the many advantages of these controllers.
The FX3U series that is now being launched worldwide is the third generation Mitsubishi Electric's extremely successful family of compact PLCs. The new flagship line once again sets new standards - and not only in the compact controllers class. The FX3U takes compact controllers into another dimension, delivering performance that was formerly the exclusive domain of larger control systems in a compact package.
|
|
Features include:
Fully certified by TUV to IEC 61508 SIL 3 and EN 954 Category 4
Scalable to any need; capable of overseeing the safety needs of an entire production line or a single machine
Leverages the existing programming & maintenance tools of the GX Developer engineering suite
No special programming techniques to master; learning curve is short
Extensive diagnostic and security features
Uses the open CC-Link Safety device level network to connect remote I/O for safety critical devices
|
|
|
|
|
|
The world’s smallest controller with a built-in touch screen, I/O and networking, plus removable mass data storage.
Built on the highly successful XLe chassis and feature set, the XLt is equipped with a larger, high-resolution resistive touch screen. Its advanced transflective readable display means the XLt is ideally suited both for indoor AND outdoor use even in direct sunlight!
Supported by the latest CScape 8.6 software there are four models available featuring flexible levels of I/O. The XLt duplicates the extensive communications options of the XLe - which currently boasts support for Ethernet, PSTN Telephone modem, GPS receiver and GSM/GPRS Modem technology.
-160x128 pixel graphical display, with a high-resolution resistive touch screen for detailed user interface
-Four programmable function keys plus system button
-Philips ARM7 Core with 1.2 ms/k scan time
-256 kB internal memory with up to 2GB MicroSDT mass-memory storage
-Two RS232/485 Serial Ports as standard
-CsCAN standard
-Add-on Ethernet, GSM/GPRS, PSTN Modem, even a GPS receiver
-Designed for IP65/NEMA 4X environment; panel or DIN-rail mountable (1/4 DIN Package 96x96mm)
-XLt supports a wide temperature range (0 to 60°C)
-9 - 30 VDC supply range
-Available in Grey/Black&Blue or with Custom colours
~ Cscape™: All Units are programmable with a Free Software ~
|
|
|
|
|
|
Vision130™ Connects!
PLC, HMI & onboard I/Os plus ETHERNET, SMS/GPRS, CANopen, MODBUS...
The Vision130™ is a palm-sized PLC with a built-in Operator Panel. The panel offers a graphic display screen and keypad. This small, powerful device supports up to 166 I/Os (onboard plus expansion modules). A rich range of embedded features include multiple auto-tuned PID loops, internal 120K structured database, loadcell support, and communication options such as Ethernet, GSM/SMS, MODBUS, CANbus, function blocks that enable Vision to communicate with devices using proprietary COM protocols, plus remote access and data export software utilities.
The Graphic HMI display screen can show images, text, and graphs according to real-time parameters. It can also display graphs based on historical values, to reflect trends of recorded data. Vision130™ supports up to 1024 user-designed screens, and up to 500 images per application.
The Vision130™ is unique: it enables engineers and systems designers to benefit from a powerful PLC and a graphic HMI – within a bare minimum of budget, cabinet space, and wiring.
Our PLC/HMI integrated devices:
save our customers’ programming time, wiring, and cabinet space.
cut budget by reducing requirements for additional hardware
prevent you from wasting time setting up Panel-PLC communication
|
|
|
|
|
|
The XL6 All-in-One controller with a built-in 32,000 colour TFT touch screen, I/O-Modules, networking options, removable MicroSDTM Card and USB ports. It’s programmable by Horner APG’s industry recognised CscapeTM software and can control a wide range of different processes and machines from small to medium applications.
-Touch-based screen
(1/4 VGA), 32,000 colour touch screen with Screen Operating Temperature from -10 to +60 degrees centigrade.
-Programmable hard keys
5 fully programmable function keys plus system key for easy diagnostics
-Capable controller
256KB Logic Space, Screen Update Speed is Adjustable with Logic Scan upto 0.2mSec/K logic.
-Single Programming Software
One software for logic and screen development. IEC61131 Compliant
-Wide Range Power Supply
Suitable for Mobile and Industrial Applications.
-Integrated I/O
4 different combination of built-in I/O available with Colour Coded Connectors
-2 serial ports
Connect to a choice of many serial protocols for PLC, Drives and other devices or our Serial I/O System
-CANOpen port
For connecting with other devices, OCS products or remote CsCAN I/O’s to expand system capabilities
-USB Transfer
New data transfer available with XL6.
~ Cscape™: All Units are programmable with a Free Software ~
|
|
|
|
|
|
Jazz™ PLC HMI:
Much more than a "smart relay"
The new Jazz™ by Unitronics is a PLC that includes on-board I/Os plus a full-function Operator Panel with numeric keypad. It enables users to replace the "smart relays" with a smarter, more powerful device, while keeping the same low budget.Jazz's™ PLC capabilities include 24K (virtual) of Ladder programming, functions such as math, store/load, compare, interrupt and loops.
The Jazz's™ fully-functioning HMI provides 60 user-designed screens, an alpha-numeric keypad and a multi-lingual display. The HMI helps our customers boost productivity by displaying operating instructions, system-fault messages and conditional data.
Jazz™ features a variety of communication options, including SMS messaging, Remote Access utilities, and PC access via MODBUS or OPC/DDE servers.
This unique combination of features, along with the Jazz's™ remarkably low price make it perfect for any application- from simple electric boards to complex production lines. Its High-speed inputs, combined with remote communication options make it the right choice for water and agriculture applications. Industrial lighting, automatic barriers/doors and air conditioning can also be easily and economically controlled by the Jazz™.
|
|
OCSXL Series - Programmable Logic Controller and Operater Interface
Quality Graphics Display for Better Process Visualisation and Machine Indication
More Compact and Affordable than Separate PLC and Operator Interface
Built-In I/O with Removable Terminal Blocks for Easy Wiring
Removable Mass Data Storage Memory Card - Supports Data Logging
|
|
|
Programmable Logic Controllers, along with easy-to-use Support Software, are available to flexibly handle applications from small-scale equipment to entire production lines with Programmable Logic Controllers such as those in the SYSMAC CJ1, CS1 and other series.
|
|
Control Terminal CT200 series
* Display: 5.7" QVGA / 5.7" VGA, color-TFT, opt. Touch-Screen
* Processor: AMD Geode LX800, 500 MHz
* Operating memory: 256 / 512 MB
* Compact flash: ≥ 512 MB
* Operating system: VxWorks®
* Interfaces: Ethernet, USB, RS232/422/485, CAN
* Visualization: M-JVIS Designer, Java programming
Control Terminal CT300 series
* Display: 6.4" VGA / 10.4" VGA, color-TFT, opt. Touch-Screen
* Processor: AMD Geode LX800, 500 MHz
* Operating memory: 256 / 512 MB
* Compact flash: ≥512 MB
* Operating system: VxWorks®
* Interfaces: PS/2, Ethernet, USB, RS232/422/485, CAN
* Visualization: M-JVIS Designer, Java programming
|
|
The MSX-Box is a real-time PAC system (Programmable Automation Controller) based on open source. The system is optimized for industrial industrial measurement, control and regulation tasks in real time.
- No need to take care of updates, no software license costs: Operating system Linux with RTAI real-time extention
- Full machine time only for your application
- Individual application design through free access to the source code
- Free development tools
- Standard components such as PCI backplane, standard Ethernet, …
- For all PCI boards with Linux drivers
- Secured investment: long-term product availability
|
|
Programmable Automation Control MAC-3500
The MAC-3500 Series are powerful modules for analog an d logic control, friendly programmables by Function Blocks for an easy realization of infinity of projects. The MAC-3500 Series allows to work as RIO (Remote Input Output) or directly like a PLC. Optionally, can be transmit by Radio, Ethernet cable or WiFi.
|
|
The LEADAIR is a system to optimise the management of several compressors running together.
Energy savings
Reduction of the working pressure
Information on the compressors’ status
|
|
|
|
|
|
The modular world of DIAS is multifaceted and opens up almost inexhaustible possibilities. During development, we concentrate on simple, flexible, safe, inexpensive and, most of all, extremely fast solutions.
Our I/O systems are available in three different series: DIAS, C-DIAS and P-DIAS. All of these product series can be implemented in a modular or decentralized configuration and make a strong impression with their compact design and flexibility. The different series can be combined as desired.
SIGMATEK’s extensive experience has bred a multitude of standard modules.
Highlights DIAS series:
- I/O stations consist of a terminal block and a function module
- Easy exchange of function modules, without having to disconnect the block wiring
- 3-wire connection technology
- Compact design
Highlights C-DIAS series:
- Highly compact design with high package density
- Individual modules simply plugged onto the module carrier
- Fast and simple wiring
- Use of prefabricated cables with connectors
- Comfortable exchange of individual modules
Highlights P-DIAS Series:
- IP67 protection
- Compatible with all other component series
- Time saving connection technology
|
|
|
|
|
|
The core of this PLC 7001 Chip is based on the PLC 7000 which has already been in use for two years. With its simplified memory interface the PLC 7001 can be easily integrated as embedded PLC into div. customer applications.
The peripheral interface offers the possibility to realize up to 56 in- and outputs, pulse duration modulation functions as well as stepper motor controls from integrated modules. For the application of decentral peripherals, the chip offers a serial I/O bus which allows operation of up to 32 digital and analog I/O modules.
In connection with an Arm9 processor there is also the possibility to operate Ethernet-based communication like TCP/IP, EtherCAT, Powerlink and Profinet.
At an operating voltage of 1.8V the power loss amounts to only 1.2W. For this reason the design is optimally suitable for the application in higher temp. ranges.
Single-Chip CPU
For users wishing to integrate a high-performance hard PLC into their application, there is a prefabricated PLC module which lead through all digital/analog and other communication interfaces to a SO-200 PinConnector. These modules can be easily integrated into various applications like board controllers, HMIs etc.
The modules as well as the chip models can be equipped with a PLC user memory of up to 2MB.
|
|
|
|
|
|
Alto RIOM is designed to become integrated into TCMS and embedded architectures. It can control local automatisms, command gateways or supervision functions : air conditioning, doors, brakes, auxilliaries, fire security.
Alto RIOM provides the monitoring of equipments on serial or CAN networks.
The connection to the upper level is MVB (Main Vehicle Bus) or EtherNet/IP.
Alto RIOM has been designed following a SIL2 level process with the conformity to EN50155 norm.
For example, Alto RIOM MVB contributes for the brakes monitoring of the Barcelona metro cars, included in the Alstom AGATE Link system.
More than 5000 products sold worldwide.
Mechanical presentation : 2.5 kg min, IP30, Fixation by screw
Robustness
- Electrical, mechanical, thermical, climatic characteristics : EN50155
- Electronic Compatibility : EN 50121-3-2 and EN50022
Power supply :
* 24 V or 72-110V -30% +25% , Tests according to the EN50155 Norm
Basic CPU with :
* 1 MVB channel + 1 Ethernet channel + 1 CAN channel
* 2 asynchronous serial links : HPTS, ASCII
Basic digital IO board
32 digital inputs + 16 digital relay outputs.
Alto RIOM can accept 2 IO boards.
* Digital input : 24V or 72-110V -30% + 25% 10 mA
* Relay output :
Tension on the contact : 16 to 160 Vcc
Max switching power : 8A 30Vcc to 0.4A 110Vcc
Option : Peripheral board
* 4 asynchronous RS232/RS485 serial links.
* 4 analog inputs +-10V, +-20mA , 12 bits, 2%
* 4 analog outputs 0-10V, 0-20mA, 12 bits , 2%
|
|
|
PLC with a built-in graphic display and keypad. With a rich variety of onboard I/Os, including direct temperature and weight measurement inputs.
|
|
|
|
|
|
LT200 : PLC for harsh environments
1/ HARDWARE DESCRIPTION
- ROBUSTNESS : each module is enclosed in a aluminium cabinet which allows a protection against electro-magnetic interference and a good thermal dissipation.
- COMPACITY: Height x Depth : 105 mm x 84 mm ; Width = 25mm x Number of modules
- MODULARITY : supports up to 15 I/O blocks. A block has between 2 and 5 modules.
The base is fixed by brackets for screwing to a grid or a plate. The width of the base is on demand.
The LT200 CPU starts at -40°C.
The Ethernet connector is suitable for vibratory environments.
* Memories : SDRAM : 32Mo (16Mo for user); FLASH : 16Mo (4Mo for user)
I/O blocks connectors are screw terminals for standard industrial use or SubD connectors for harsh environment where shocks, vibrations are more intensive (transportation systems).
2/ SOFTWARE USES
Three different embedded kernels for three different uses :
* quick parametrable system with OPAL V4 tool
* or IEC61131-3 PLC with Isagraf V5 workbench
* or C programming with SDK (Linux, GCC, GDB, Eclipse IDE)
|
|
Short description:
Panasonic Electric Works established a new world standard "SLIM" PLC. Starting from 10 I/O to 32 I/O, the CPU is only 25(w) x 90(h) x 70(d)mm. This is about 1/4 the size of the traditional bulky PLC style called "Brick". The FP0 saves precious panel space and money. Relay output types have removable screw terminal blocks. The power supply connector is also quick to disconnect. Easy installation... especially when duplicating many systems.
|
|
|
|
|
|
Micro Automation Set 24:
Fast and safe fault diagnostics for 24-V load circuits
Fault diagnostics for 24-V load circuits with LOGO! and SITOP select
Micro Automation Set 24 - Fast and safe fault diagnostics for 24-V load circuitsThe Micro Automation Set is especially suited for monitoring of DC 24 V load feeders and for detecting overload and short circuit, e.g. in following preferred fields:
* For systems with several 24-V load feeders connected to a central power supply (serves to distribute the load current)
* For selective fusing of individual load feeders to prevent the complete system from malfunctioning in the event of a fault
* For selective protection in widelydistributed system components and distant loads (distributed design)
* For consumers with high inrush current requirements which cannot be protected by quick-acting circuit-breakers
* For fast fault localization
Highlights
* Complete system shutdown is avoided since the SITOP select diagnostics module shuts down the faulty circuit. Other circuits remain active.
* Selective switch-off and display of the faulty line on the LOGO! logic module guarantee fastest possible fault identification.
* Startup and maintenance of the system can be carried out in steps. Simple insertion and removal of the blade-type fuses is sufficient.
* Additional SITOP select diagnostic modules can be easily added if the system is expanded.
* A central overview of the operating status of all load circuits is possible through text messages on the LOGO!
|
|
Nano Rack PLC
Less than 4 inches in height, the FP2SH is not only one of the smallest rack systems in the market, but one of the most powerful. The FP2 can currently support four types of networks: Ethernet, Profibus-FMS/DP, MEWNET and Remote I/O....
|
|
|
|
|
|
Our remote I/O modules from the ricos series always provide many advantages in any environment. The digital fieldbus system ricos is suitable for well-known bus systems like Profibus-DP, Interbus, DeviceNet, CANopen or Ethernet; it provides a complete range of functions.
The ricos TP modules are capable of outdoor use and easily withstand the most extreme conditions. They can stand vibrations and operation temperatures that go beyond the industrial requirements and are therefore perfectly suitable, for example, for applications in shipbuilding and railroad technology or in utility vehicles or other large vehicles.
ricos
With its fieldbus system ricos Wieland Electric offers a future-proof concept for communication between control and field I/Os. Modular I/O components are remotely installed near the machine and networked via the fieldbus. A wide range of different I/O modules process the different actuator/sensor signals. Comprehensive diagnostic functions enable the user to easily implement the modules and considerably reduce machine downtimes.
|
|
|
|
|
|
High-end Performance in a Compact Package
PLC systems from Mitsubishi Electric are pioneering technology leaders delivering exceptional reliability and performance. We close the gap between the automation and the IT levels.
The iQ Platform MELSEC System Q –
Tomorrow’s Controller Platform Today
• Flexible and scalable automation architecture
• PLC, motion, robot and NC technology on a single platform
• PLC CPU with a cycle time of just 9.5ns
• Integrated Ethernet port
• Self-diagnostics with error history integrated in the CPU
• Supports memory expansion up to 32MB
• Supports remote diagnostics and programming
• Flexible, cycle-oriented data management with a data logger module
• Smooth communication with the management IT level via MES and MES IT Interface Module
• Application-oriented Safety PLC solutions with safety relay module and safety PLC, including a secure network
• Caters to special requirements of process and hybrid applications with process PLC and ready-to-use closed-loop control algorithms
• Enhanced system availability with redundant PLC architecture using standard components
• Remote I/O systems with hot swap functionality
• Comprehensive portfolio of I/O modules
• Programmable with IEC 1131.3/EN 61131-3 compatible software, or in high-level languages like C++ and Visual Basic with a PC CPU
• Soft PLC available for the PC CPU
|
|
|
|
Programmable logic controllers
