SPECIAL MIXERS
with PP - PVDF - AISI 316 IMPELLER and SHAFT
with plastic impeller and shaft, designed to process aggressive chemicals
with gear drive for high-viscosity liquids, available with plastic or metal impeller and shaft
with AISI 316 stainless steel impeller and shaft
POWER RATING:
from 0.13 HP to 0.75 HP
SHAFT LENGTH:
PP and PVDF from 600 to 1400 AISI 316 from 850 to 2000
MOTOR:
direct or gear
220, 380 or 12 V from 35 to 940 rpm
WEIGHT:
from 5 to 14.5 kg
|
|
AGIPRO - MIXEL Agitator for container
Are you looking for THE economical and efficient tool to mix liquids into 1000 litres cube-like containers?
The set < Agipro 125 quick agitator with fixing holder for container › is made for you.
The fixing holder has been especially designed to enforce stability of the AGIPRO agitator and to maintain it on a 1000 litres cube-like container in total safety. You can use Agipro 125 quick agitator for mixing, homogenization, storage or suspending solids into liquid.
The MIXEL agitator AGIPRO 125 (or AP 125) is designed to mix liquids into 0.5 to 1.5 m³ tanks.
Technical specifications:
- MIXEL TT type propeller – diam. 125 mm
- Motorization 0.75 Kw at 1500 rpm
- Agitation shaft length 1200 mm
|
|
Made in lengths of up to three meters, complete with PVC support plate. They may be supplied, with axial-flow or centrifugal flow, with a rotation speed from 2800 to 600 rpm on the work they have to perform.
Due to their constructional detail they are suitable for use in purification and neutralisation plants and for the mixing of reactants, additives and flocculants in tanks with volumes of up to 20 m³.
|
|
Metso Minerals Attrition Scrubbing machines are simple, yet highly efficient units for scrubbing particles at densities of 70 - 80% solids.
Two opposed Helix type propellers on each shaft force particles against each other, resulting in intense scrubbing, polishing and disintegration. Efficiencies generally increase with and increase of the density of the pulp, as particles have more frequent grain to grain contact. The twin propellers, mounted on a shaft inside a tank, are supported by a heavy-duty steel structure. Shafts are coupled to either gearbox or spindle bearing drives. An opening in each cell partition allows pulp to flow through the machine. Machines are usually supplied with two, four or six cells, with each cell ranging in volume from 4 to 9900 liter’s. (1cubic foot to 359 cubic foot). Odd cell arrangements are also available as custom supply
|
|
Agitator for digestion or methanization tank
Sludge coming from waste water plants is full of methane.
In order to reduce volume of sludge (30 to 40%) and to deodorize it, sludge is transformed inside a digestion or methanization tank.
An agitator turns in this heated tank, separating methane from sludge. This methane is collected at the top of the tank and used to heat tank.
Then, digested sludge is dehydrated and used to fertilize agricultural soil.
MIXEL has designed a new agitator for equipping digestion or methanization tank:
- vertical agitator, with double level of propellers (TTF profiles propellers, with converging edge to avoid aggregation of tows;
- agitation shaft up to 20 m
- hydraulic seal
- Guiding turret.
MIXEL has equipped up to 5000 m³ digestion tanks, in France, Algeria and Marocco.
|
|
MIXEL - Agitator for preparation and production platform
If you firm designs and makes:
- Machines for preparing flocculants, reagents, coagulants..., for blending or for measuring out...
- Platforms for making chemical products, cosmetics...
And if you are looking for quick, economical, easy to handle and to integrate agitators, the agitators of the new range Agipro from MIXEL meet those criteria.
A SMALL RANGE: 4 sizes of agitators for mixing into 0.5 to 8 m³ tanks
Agipro AP 125 - Tank from 0.5 to 1.5 m³
Agipro AP 250 - Tank from 1.5 to 3 m³
Agipro AP 400 - Tank from 3 to 5 m³
Agipro AP 600 - Tank from 5 to 8 m³
3 VALUE ADDED ACCESSORIES
Clamp for fixing agitator on tank edge
Square flange for fixing agitator on top of tank
Fixing holder for 1000 litres storage tanks
|
|
Technical description:
• Mounting and dismounting of the agitator when the wine tank is full after connection on your ball valve. The shaft has to be slided inside the tank. The propeller fans out when rotation.
• Motor : 1.1 kW, 1.5 kW or 2.2 kW-230/400V-50Hz
• Sealing : mechanical seal
• Handiness : carrying handle
• Integrated on/off switch on motor electric terminal box
• Hands safety device
Design, manufacturing and tests in our workshops.
|
|
|
|
|
|
MIXEL - New range AGIPRO - Standard, practical and economic agitator. Four different sizes of 316 L stainless steel mixers are avalaible, for tanks from 0.5 to 8 m³.
A range of multi-purpose, optimum efficiency, easy to handle and easy to install agitators.
THE PURPOSES of AGIPRO quick mixer:
- all liquid mixtures, homogenization, suspending solids
- for tanks from 0.5 to 8 m³
- for products of 1 to 4000 cps viscosity
- for all industries (water and effluents treatment, food processing, chemistry, paper industry...)
- preparation of reagents, paint and varnish, coagulation, neutralization.
THE RANGE - How to choose the right AGIPRO quick agitator?
Recommendation for product viscosity = 1 cps
- 0.5 to 1.5 m³ tank-- AP 125 /0.75 Kw at 1425 rpm /propeller diam. 125 mm
- 1.5 to 3 m³ tank -- AP 250 /0.37 Kw at 280 rpm /propeller diam. 250 mm
- 3 to 5 m³ tank -- AP 400 /0.55 Kw at 145 rpm /propeller diam. 400 mm
- 5 to 8 m³ tank -- AP 600 /1.1 Kw at 138 rpm /propeller diam. 600 mm
ACCESSORIES - What to do with?
- stainless steel clamp for fastening agitator on tank edge (for AP 125, AP 250 and AP 400 only)
- square stainless steel flange for fastening mixer on top of the tank (available for the four sizes)
- fixing holder (special galvanised steel support) for fastening agitator on 1000 litres cube-like container (for AP 125 only)
DELIVERY TIME
15 days from reception of both order and payment
Phone to our technical and sales department at +33 (0) 4 72 52 18 18 or through contact@mixel.fr
|
|
|
|
|
|
AGIMAG - Magnetically driven agitation - for ultimate leak tightness
Designed to be cleaned and sterilized (in place or in autoclave) and build with FDA components, the AGIMAG® agitators from MIXEL are optimized for all the pharmaceutical, cosmetics and food processing.
INDUSTRIES CONCERNED
Pharmaceuticals, food processing,
light chemicals, cosmetics
APPLICATIONS
* storage
* mixing low viscosity products
* fermentation
PERFORMANCE
From 10 litres to 10,000 litres (enquire for higher
capacities)
High pressure (up to 16 bar)
Up to 150°C
FDA approved MATERIALS
316 L stainless steel polished to Ra < 0.2µm electrolytic
polishing
Bearing blocks made from silicon carbide with no free
silica (other configurations please enquire)
POWER
0.18 to 2.2kW
Transmission by magnetic coupling
MAJOR INNOVATIONS
- tachometer built into agitation head (cleanness,
control, safety by instant stopping of drive)
- clutch device for the magnetic coupling
(maintenance operations made easier)
- compliant with EHEDG cleanability criteria.
|
|
AGIPRO - Portable agitator with clamp
Are you looking for a vertical, economical, light and practical agitator, easy to handle from a tank to another?
The set MIXEL ‹ Agipro quick agitator with clamp for fixing on tank edge › is made for you.
The fixing clamp has been especially designed to be heavy-duty and for safe use. It can be easily fixed on tank edge and does not vibrate when agitator works.
This clamp fits to the following sizes of agitator:
- Agipro AP 125 - Tank from 0.5 to 1.5 m³ - 0.75 Kw at 1500 rpm - weight 15 kg
- Agipro AP 250 - Tank from 1.5 to 3 m³- 0.37 Kw at 280 rpm - weight 20 kg
- Agipro AP 400 - Tank from 3 to 5 m³ - 0.55 Kw at 145 rpm - weight 30 kg
|
|
|
|
|
|
Immersed agitators TR 14 to 226
Pumps of recirculation RZP
BEACHES Of USE
Diameter of the pale ones: 14 cm to 2,6 m
Pushed: 45 to 5000 NR
Nominal nominal output: 0,5 to 18 kw
Number of revolutions of the pale ones: 17 to 1450 tr/min
Depth of immersion max: 20 m
Beaches of temperatures: 3 to 40 °C
APPLICATIONS
Homogenization, put in suspension, circulation of effluents in any type of basin
Adapted to the urban cleansing and the water treatment, the range of agitators Salmson d' Emu Technology covers the following applications: post raising, zone of contact, anaerobic zone, zone anoxia, activated sludge basin (circular, rectangular, in channel...), covers with
muds, pit with greases, basin plug, basin of storm...
In industry, homogenization of various fluids, put in suspension of charged, corrosive or abrasive fluids
ADVANTAGES
In comparison with the standard ISO 21630, agitators TR have a high specific push in comparison with competition
Tight entry of cable, protection against traction
Oblique rolls of the dice guaranteeing one long life of life
Room of sealing preventing all risks of oil escape of the mechanical seal
Option: probe moisture in the room of sealing
Carbide mechanical seals of silicon and radial joints of axis
The pale ones of the propeller are rigidified so as to obtain the best possible hydraulic effectiveness
Various stages of gears allowing a great beach speed for an optimal result
|
|
Fixed Angle Applications - For blending, homogenizing and temperature uniformity duties
Swivel Angle Applications - For tank cleaning operations and the preventions of harmful sludge build-up
Pipeline Power Mixers - For the petrochemical industry
Unique Advanced Propeller Design - Featuring high pumping, high thrust, minimum power draw, no cavitation, solid reliability
Unique Side Entry Mixer Tank Shut-Off Device - Permits the bearings and mechanical seal to be changed under full tank conditions
|
|
High Pumping
High Thrust
Minimum Power Draw
No Cavitation
Solid Reliability
|
|
Inside crude oil (or products issued from oil) storage tanks, side entry mixers designed by MISSENARD-QUINT :
- avoid the main deposits, which permits a wider exploitation
- disperse salty pockets of water included inside petrol.
- homogenise crude contained inside tanks.
- melt products issued from crude oil to obtain finished products
CHARACTERISTICS
1. fixed angle or swivel angle (manual orientating device)
2. transmission
. bevel gear reducer (type F 1003)
. pulley-belts (type F 1201)
3. sealing
. stuffing-box (P)
. single mechanical seal (G)
. double mechanical seal (GD)
. single mechanical seal + stuffing-box (PG)
Nota: device for the replacement of the mechnaical seal in full tak condition
4. range of power from 4 to 55 kW
5. protection of the mechanical seal
. steamed reheating
. steamed cleaning (vapor quench)
Design, manufacturing and tests effectuated in our workshops.
Note : We also manufacture side-entry mixers specifically design for food insdustry.
|
|
|
Flygt mixers are used in a wide range of mixing duties such as solids suspension, liquid blending and destratification. Submersible mixers have a compact design, which together with Flygt’s installation methods makes them easy to install both in new and existing tanks. They can be found in operation at wastewater treatment plants, on oil and gas rigs and supply ships, in aqua and agriculture and in the steel and metal industry. Unlike their dry-mounted counterparts, submersible mixers provide unlimited freedom of positioning and orientation. By utilising this freedom, the mixer jet is allowed to develop and create efficient mixing of the entire volume. Flygt’s compact mixers are made of stainless steel and provide a cost-efficient alternative for most mixing applications.
|
|
It is the agitator the more installed, generally on the top of the tank (as showed hanging configuration or associated to a bottom bearing), either on the bottom of the tank.
It is composed of :
. one driven head out of the vessel
. one agitation axis with one or several stages of agitating parts
The picture shows a configuration type hanging which in function of the case (constraint regarding to kinematic chain) has to be associated to a bottom bearing.
The interface driven head / vessel can be equiped with different type of sealing :
. mechanical seal
. gasket
. drip
. stuffing box
Design, manufacturing and tests are effectuated in our workshops.
|
|
Chemineer Agitators are robust, simple and designed for ease of maintenance. The drive has a minimum of moving parts, while NC machining of the housing and the subassemblies ensures trouble-free interchangeability and precision parts mating.
Engineered for the ultimate in process compatibility, Chemineer manufactures a range of agitators to suit almost all applications
Available in drive sizes from 0.25 to 1,000 kW - even more for specialized applications. A wide selection of mounting methods, materials of construction, shaft seals, shafts, impellers and accessories can provide the best turbine agitator for virtually any process.
|
|
In the delivery state (clamping ring barrel) the material is prepared and conditioned for use and transfer to the spray gun. Due to the pneumatic lid lifter, an empty barrel can be replaced easily with a full one. System components:
- Lid for attaching apparatus
- Pneumatic lid lifting device
- Agitator (electric or pneumatic powered)
- Pump with material filter
- Agitator switch off when lid is lifted pneumatically
- Compressed air fittings
All agitators are tested and certified in accordance with ATEX 94/9/EC. Versions without explosion protection are also available.
10 years of delivery guarantee for spare parts
|
|
Differents types:
Direct Drive Agitator - Air Powered direct drive agitator assembly with 1/2 hp air motor and a three bade propeller to keep materials in suspension even with high solids.
Indirect Air Motor Drive - Standard duty, smooth running with gear reducer, 1/2hp, 15:1 ratio, 20 to 120 RPM. Inc throttling valve, fittings and hoses for connection to air supply on tank lid. Air consumption is approx 6CFM @ 50RPM.
Reciprocating Air Motor Drive - 180° reciprocating action provides excellent agitation of all types of materials. Particularly important for waterborne shear sensitive materials. Very low air consumption
|
|
(speed rotating electric-agitators removable and swivel angle)
Advantages of those agitators : they will help you, not only to resolve your mixing problems, but will make their maintenance easier.
1. EFFECTIVE
- mixers claimed by satisfied customers
2. ROBUST
- designed to long with time resistant components
3. WITHOUT MAINTENANCE
- 20 000 h of operation without maintenance
- lubricated bearings for life
4. THREE STANDARD MODELS
- power 0.37 kW, 0.5 and 0.75 kW
5. EASY SETTING OF THE MIXER ON THE TANK
- claw device to tighten as vise principle
6. FAST DISASSEMBLING/REASSEMBLY OF THE SHAFT
- tightening with chuck
7. SHAFT AND PROPELLER
- stainless steel or any other material on request
Design, manufacturing and tests in our workshops.
|
|
Description
Faggiolati's mixers are projected for optimal mixing, homogenising and agitating operations in civil and industrial waste-water purification plants. The high performance ratings allow a considerable reduction in running costs.
The non-clogging propeller profile, combined with an accurate projection, guarantees optimal running condictions with absolute reliability.
Applications
Thanks to their versatility, Faggiolati's mixers can be used in a wide range of applications. The combination of various construction materials, the stainless steel propellers and bouble silicon carbide mechanical seals allow the use of these mixers in highly corrosive conditions and at high temperatures. Typical applications for these types of mixer are:
- homogenisation of heavy sludge or liquids with solid particles
- Removal of sedymentary deposits.
- to avoid ice formation.
|
|
Sterling Halberg sludge mixers of the MFS type ensure intensive treatment of sludge is possible in cylindrical, cylindrical-spherical or egg-shaped digesters. By reversing the flow direction important progress requirements are fulfilled.
• TECHNICAL DATA
- Flowrate:350 – 7200 m3/h
- Speed:1500 – 420 rpm
- Direction of rotation:cw and ccw
• FEATURES
- uniform operation in either direction
- heavy duty construction
- low energy consumption
- suitable for digesters of concrete and steel
- automatic lubricating system
- direct drive
- uniform distribution of temperature
- sturdy propeller construction
• ADVANTAGES
- thorough and uniform mixing
- long term use without dismantling
- low operating costs
- adaptable installationlow cost of up keep
- no V-belt maintenance
- improved sludge fermentation
- suitable for many different sludge conditions
|
|
|
FLUX offers a complete range of mixers for agitating, mixing, stirring or homogenizing operations within containers of 30 to 30.000 Litres. The complete range of mixers is based on a modular design, allowing the user to select the individual component parts to meet his specific requirements.
|
|
Centrifugal turbine agitators designed for proper agitation of water solutions or lower viscosity liquids in tanks with a capacity between 100 and 300 L/H (26-80 GPH).
It features a double action centrifugal turbine:
Three long distance radial jets, with sweeping effect arround the turbine to produce the rotation of the liquid.
Three axial jets to stir the bottom and create a vertical stream.
|
|
Standard range: HELISEM®
The HELISEM® line, including three standard mixers, is designed for economical mixing solutions, available with short deliveries. It has a broad range of applications, including water treatment, fine chemicals and end-products industries.
Open and Sealed tank up to 250 m3.
Custom-made range: ROBIN®
The ROBIN® line of customized mixers is ideal for complex processes running in extreme conditions, best suited to the requirements of hydrometallurgy, the chemical and petrochemical industry, and fine chemicals. The list of possible applications includes alumina refining, fermentation, polymerization, phosphoric acid, resins and high viscosity products, to name but a few.
Pressure up to 250 bar
Temperature up to 350 °C
Volumes from 0.010 m3 to 10,000 m3.
|
|
The IKA-ROTOTRON is a jet flow agitator. The jet tube cares for intensive, directed flow. Therefore this agitator is especially suitable for mixing of high-viscous media, even in rectangular containers. Moreover this agitator is especially suitable for submerse incorporation into extremely big containers. This makes the use of extremely long and big agitators of common type unnecessary.
The IKA-TURBOTRON construction series does not have a fixed jet tube. Instead of the jet tube different mixing tools like propellers, turbines or toothed disks can be chosen according to the respective application.
|
|
The ROBIN® line of customized mixers is ideal for complex processes running in extreme conditions, best suited to the requirements of hydrometallurgy, the chemical and petrochemical industry, and fine chemicals. The list of possible applications includes alumina refining, fermentation, polymerization, phosphoric acid, resins and high viscosity products, to name but a few.
Pressure up to 250 bar, 350 °C.
Volumes from 0.010 m3 to 10,000 m3.
|
|
All-stainless construction helps eliminate the potential for contamination in critical sanitary applications.
300 series stainless motor, gear and bearing assembly
Available in 1725-rpm direct drive, and 280- or 350-rpm gear drive
Fixed-mounted mixers available in various speeds
Washdown-rated, inverter-duty motors from 1/2 to 3 HP
Oversized bearings with L10 life exceeding 100,000 hours
Permanent sealed lubrication
Flexible motor coupling
Solid 300 series stainless steel flanges
|
|
Agitators
This is one of the most comprehensive agitator lines in the industry, including fast seal removal, coaxial with independent drives, magnetic drive for non-polluting production and sterile product treatment, side entry, and compact designs. Many options are available, including standard or customized agitators, as well as systems.
The manufacturer is one of the world's leaders in agitator engineering and is 9001 certified.
|
|
The HELISEM® line, including three standard mixers, is designed for economical mixing solutions, available with short deliveries. It has a broad range of applications, including water treatment, fine chemicals and end-products industries.
Open and Sealed tank up to 250 m3.
|
|
|
|
